A
Specifications

External Power Supplies

Internal Antenna APs
External Antennas
This appendix lists the specifications for the AP3935i and AP3935e access points and an external 12V
DC power supply.
Table 5: Specifications for the AP3935i and AP3935e
Item
31012
31013
31014
31015
Enclosure material
Power source
Power consumption
Outside dimensions (max)
Antenna (AP3935i only)
Uplink Interface
RoHS compliant
Radio Configuration
Operating temperature
External Power Supplies
AP3935 APs may be powered by IEEE 802.3af compliant PoE cables connected to the Ethernet ports in
the connector bay. This is usually the preferred method of powering for users that plan to mount the
ExtremeWireless™ AP3935i & AP3935e Installation Guide
Specification
WS-AP3935i-FCC
WS-AP3935i-ROW
WS-AP3935e-FCC
WS-AP3935e-ROW
Metal base, plastic cap
PoE 802.3at for full performance; (802.3af for low
performance mode) DC power supply.
20W (Max.) 17.0W (Average)
Length: 215 mm (8.46")
Width: 215 mm (8.46")
Thickness (not including mounting bracket):
AP3935i: 56 mm (2.2")
AP3935e: 57 mm (2.23")
8 ports: 4 (Radio1) ports (5GHz antenna), 4 (Radio 2)
ports (2.4GHz antenna)
GbE Ethernet x1 with PoE
Yes
Dual Band Dual Concurrent 802.11ac and 802.11n
Radio 1 IEEE 802.11ac, 5GHz, 4x4:4 MU-MIMO, 20/40/
80MHz channel (up to 1733 Mbps per radio)
Radio 2 IEEE 802.11n, 2.4GHz, 4x4:4, MCS8, MCS9, 20/
40MHz channel (up to 800 Mbps per radio)
32° F to 122° F (0° C to +50° C)
