Figure 3: AP3935 Bottom View
1 Reset Button
2 Console Port
AP3935 LED Indicators
Both models of the AP3935 have the LED indicators, shown in
below. The LEDs provide status information, described in
on the current state of the AP3935. For more information, see the
Figure 4: AP3935 LEDs
ExtremeWireless™ AP3935i & AP3935e Installation Guide
3 LAN Ethernet Ports 1 and 2
4 External Power DC 12V
Figure 4: AP3935 LEDs
Table 3: AP3935 LED Indications
ExtremeWireless User
Introduction
on page 11
on page 12,
Guide.
