- Page 1 Atom ID0406-6.5 Indoor CPE User Manual February 2020 Version 1.9...
- Page 2 Copyright Notice Baicells Technologies, Inc., copyrights the information in this document. No part of this document may be reproduced in any form or means without the prior written consent of Baicells Technologies, Inc. Disclaimer The information in this document is subject to change at any time without notice. For more information, please consult with a Baicells technical engineer or the support team.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION .............................. 1 FEATURES ............................... 1 PARTS LIST ..............................2 DESCRIPTION ..............................2 INSTALLATION & CONFIGURATION ......................... 4 ..........................4 HYSICAL NSTALLATION ..........................7 ASIC ONFIGURATION 5.2.1 Check Status Icons ..........................7 5.2.2 Change the Password ........................8 5.2.3 Configure the Network / Operation Mode .................. - Page 4 19: T ......................16 IGURE HROUGHPUT TATISTICS 20: APN S ..........................16 IGURE TATUS 21: D ..........................17 IGURE EVICES 22: WLAN S ........................17 IGURE ETTINGS 23: W ........................... 18 IGURE IFIDOG 24: W ..........................18 IGURE HITELIST 25: A ........................
-
Page 5: Introduction
Introduction The Baicells Atom ID04/06-6.5 indoor user equipment (UE) is part of the Baicells broadband wireless access system that integrates with Long-Term Evolution (LTE) backhaul networks to provide subscribers with Internet access. The UE, also referred to as Customer Premise Equipment (CPE), communicates through a wireless connection to the operator’s eNodeB’s (eNB) at cell sites located in the region. -
Page 6: Parts List
DC-5V Power Adaptor RJ-45 Ethernet Cable Description The Baicells Atom indoor UE is a small, compact unit that sits on a desktop, bookshelf, or other flat surface inside the building (Figure 2). Figure 2: Dimensions On the top of the unit is a card slot for the Baicells Universal Subscriber Identity Module (USIM) card provided through the operator or distributor. -
Page 7: Figure 3: Leds & Interfaces
The LED indicators on the front provide operational status information (Figure 3). Refer to Table 2 for a description of the LEDs. Various connection interfaces are on the back of the unit, as well as a small LED for the Local Area Network (LAN) connection. For a description of the interfaces, refer to Table 3. Figure 3: LEDs &... -
Page 8: Installation & Configuration
Table 3: Interfaces Interfaces vary by model; not all models will have all of the interfaces listed. Interfaces Description USIM Universal Subscriber Identity Module card slot. 1.8V/3.0V USIM 2FF One to four RJ-45 ports, LAN, 10/100 (CAT4) or 10/100/100 (CAT6/7) auto- sensing, auto-MDX interface to connect to computer or other network devices (e.g., hub or switch). -
Page 9: Figure 5: Login
Access the GUI to check the signal: a. Open a Web browser, and in the address bar type http://192.168.150.1 press Enter. http://192.168.254.1 NOTE: If the address does not open the GUI, try http://192.168.1.1. These were used for older generation UEs. b. -
Page 10: Figure 6: Check Status
Figure 6: Check Status Connect Wi-Fi: a. Ensure that the computer or other smart device has Wi-Fi (WLAN) enabled. b. When the Wi-Fi LED on the unit shows “steady on”, per Table 3-1 LEDs, it is functional. Wi-Fi function can be enabled or disabled through the GUI. c. -
Page 11: Basic Configuration
Basic Configuration Reference: Baicells Configuration & Network Administration Guide The basic configuration settings allow you to get the UE up and running, i.e., connected to the Internet. Other features as well as more in-depth information about the UE GUI are covered in the document referenced above. -
Page 12: Change The Password
5.2.2 Change the Password To secure access to the UE, Baicells strongly recommends that you change the GUI password from its default value and record the new password in case you forget it. The password may be 5 to 8 ASCII characters (letters, numbers, and special characters). -
Page 13: Configure The Network / Operation Mode
IP address. Selecting Bridge mode disables NAT and allows the UE to function as a DHCP server without IP address conflict. Optionally, in CAT6/7 you have two other choices, Router mode and Tunnel mode. Baicells does not recommend using Router mode. The Tunnel mode may be used if, for example, you want the UE to connect to a business's Virtual Private Network (VPN). -
Page 14: Configure The Connection Method / Network Selection
Figure 11: CAT6/7 Tunnel Mode 5.2.4 Configure the Connection Method / Network Selection You can set the UE to connect to the default network automatically, or you can connect manually, where you have to select the network you want to connect to each time. 1. -
Page 15: Configure The Scan Method / Cell Selection
5.2.5 Configure the Scan Method / Cell Selection The Scan Method / Cell Selection setting has to do with how the UE selects the best wireless signal between it and an eNB for its connection to the LTE network. The setting determines which frequencies the UE’s routine scan of available frequencies will cover. -
Page 16: Figure 14: Frequency Lock / Dedicated Earfcn
Figure 14: Frequency Lock / Dedicated EARFCN Figure 15: PCI Lock... -
Page 17: Configure Apn Management / Profile
CloudCore to connect to the backhaul, the APN establishes one connection between the UE and the EPC (core network) via the eNB. Baicells CloudCore EPC, as well as eNBs operating in HaloB mode, support only one APN, which is configured by default. - Page 18 Apply To Select No Specified, TR069, SNMP*, or SNMP+TR069* to indicate which protocol may be used to collect information about the eNBs to which this UE connects. *CAT4 only Username and In CAT6/7, optionally you can enter a username and password to require users to Password authenticate before using the APN.
-
Page 19: Basic Maintenance & Troubleshooting
Basic Maintenance & Troubleshooting References: Baicells Configuration & Network Administration Guide, Baicells Operation, Maintenance, & Troubleshooting Guide Some of the common GUI menus and fields you may need to use, either yourself or through support from your service provider, are covered in this section. The examples are from a CAT4 UE, and do not necessarily reflect the information you will see for your UE due to different models. -
Page 20: Throughput Statistics
6.3.3 Throughput Statistics To see how much data is flowing through the UE, and to see how fast the traffic is moving uplink (to the eNB) or downlink (from the eNB), scroll down the Status > Overview window to the Throughput Statistics (Figure 19). -
Page 21: Devices List
Figure 22: Devices List 6.3.7 WLAN Settings (Model EG2030C only) The Baicells CAT6/7 Indoor UE, model EG2030C, has built-in 802.11 Wi-Fi capabilities, providing converged LAN and Wireless LAN (WLAN) interfaces into one integrated LTE service. The Wi-Fi uses 2.4 GHz unlicensed spectrum. For model EG2030C, you can configure up to 4 independent Service Set Identifiers (SSIDs) on the local network. -
Page 22: Wifidog
NOTE 1: The feature requires a connection to an authentication server to function. NOTE 2: Wifidog is not recommended for Baicells UEs using Power over Ethernet (PoE). You can create a whitelist to identify which website addresses, or URLs, users are allowed to reach. -
Page 23: Connect Limit (Cat6/7 Only)
In the Advanced Settings tab (Figure 26), if you want all hotspot users to use the same authentication server and login requirements, enter the server path information and set the Check internal field (maximum time, in seconds), for logging in and the Client timed out field (maximum amount of time before failure to authenticate times out, in minutes). - Page 24 Figure 27: Connect Limit...
