About This Document This document is intended for personnel who will be installing the Baicells Stellar227 Indoor 2x250mW gNB product. The product overview is followed by the procedures for properly installing. Please be advised that only personnel with the appropriate electrical skills and experience should install this device.
For the safety of installation personnel and for the protection of the equipment from damage, please read all safety warnings. If you have any questions concerning the warnings, before installing or powering on the base station contact the Baicells support team. Warning IMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger.
1. Overview Introduction The Baicells Stellar227 is an advanced indoor 5G Sub-6G integrated base station (gNB), which is designed and developed based on Qualcomm 5G SoC solution. This 2x250mW gNB is low power, subminiature and easy to maintenance. This product helps operators to enhance the coverage performance of 5G networks effectively, improve the capacity of 5G networks and eliminate the blind district, meanwhile it also can help to reduce the system power consumption.
Appearance The appearance of Stellar227 is shown in Figure 1-1. Figure 1-1 Stellar227 Appearance The Stellar227 interfaces are described in Table 1-1. Table 1-1 Stellar227 Interface Description Interface Description 12VDC power supply interface RJ-45 interface (GE), used for initial configuration or...
Green Steady ON (Reserved) Steady ON The power supply is normal. Fast flash: 0.125s The device is starting up. on,0.125s off Green Slow flash: 1s on, 1s off The device is operating normally. No power supply or device fault. Steady ON The cell is active.
Item Description Power Supply 12VDC/POE++ Protocols Used IPv4, UDP, TCP, ICMP, NTP, SSH, IPsec, TR-069, HTTP/HTTPs, DHCP Network IPv4, HTTP/HTTPs, TR-069, SSH, Embedded EPC Management VLAN/VxLAN* 802.IQ/VxLAN 4 x status LED LED Indicators PWR/ACT/RUN/ALM RF Antenna Embedded omni antenna or 2T2R external high gain antenna with SMA connectors GPS Antenna External GPS antenna, SMA connector...
5MHz bandwidth, FRC A1-3 in Annex A.1 (QPSK, R=1/3, 25RB) standard. * Planned for future release 1.4.4 Features Item Description Voice VoNR/EPS-FB Self-Organizing Network Automatic Neighbor Relation (ANR) PCI confliction detection Traffic Offload Local breakout Local/Remote Web maintenance Maintenance ...
Page 11
Item Description Rating Operating Temperature -5°C to 45°C Storage Temperature -20°C to 65°C Humidity 15% to 85% RH Atmospheric Pressure 70 kPa to 106 kPa Power Consumption Maximum 30W Weight < 2.4 lbs/ 1.1kg Dimensions (HxWxD) 7.9 x 7.9 x 1.9 inches / 200 x 200 x 49 millimeters Installation Ceiling or wall mount...
2. Installation Preparation Packing List Before opening the box, make sure the package is in good condition, undamaged and not wet. During the unpacking, avoid potential damaging impacts from hits or excessive force. Once unpacked, check the contents to see if they are consistent with the packing list. Support Materials In addition to industry standard tools, you will need the materials described in Table 2-1 during the installation.
2. Before installation, the installation personnel must be prepared with safety protection, such as: safety helmet, safety belt, reflective clothing, gloves, and safety shoes, etc. 3. Before installation, the installation personnel must cross-check each other to ensure above preparations have done. Installation Environment To get the signal coverage effect best, please place the Neutrino base station in an unobstructed space.
3. Installation Ceiling or Wall Mounting Attention: The thickness of ceiling is not less than 18mm, and bearing more than 5kgs. If the strength is not suitable, the device maybe fall off. If the ceiling is made of unstable material, such as gypsum, this ceiling installation is not recommended.
Put the gNB from top to bottom along the slot and push it to the bottom, and then clamp the spring sheet. Connect Cables Connect power adaptor to PWR port and the other end connects to AC power. Connect Ethernet cable to WAN/POE++ port and the other end connects to the web client.
Power on to Check LED Status Power on the gNB, and wait a few minutes while the gNB boots up. Per the previous Table 1-2 in “1.3 Appearance”, check that the LED indicators are lighting as expected.
