- Page 1 Nova442i Outdoor 4x4W eNB Installation Guide Document version: 02 All rights reserved © Baicells Technologies Co., Ltd.
- Page 2 About This Document This document is a guidance of Nova442i hardware installation for installation personnel, including the preparation of installation tools and supporting materials, the demands for installation environment, installation procedure, cable connection and power on. Accomplish the installation of the device according to this guide, the installation personnel can avoid potential damage to the device during the installation procedure, which makes sure the subsequent good running of the device.
- Page 3 For the safety of installation personnel and for the protection of the equipment from damage, please read all safety warnings. If you have any questions concerning the warnings, before installing or powering on the base station contact the Baicells support team. Warning IMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger.
-
Page 4: Table Of Contents
Table of Contents Product Overview ......................1 Introduction ....................... 1 Highlights ........................1 Appearance ........................ 2 Technical Specification ....................4 1.4.1 Technology ......................4 1.4.2 Interface ......................4 1.4.3 Performance ...................... 4 1.4.4 Modulation Levels (Adaptive) ................6 1.4.5 Features ......................6 1.4.6 Link Budget ...................... - Page 5 FAQ ........................... 18 Terminology & Acronym ................19...
- Page 6 List of Figures Figure 1-1 Nova442i Appearance ................2 Figure 1-2 Nova442i Interfaces and LED Indicators ........... 3 Figure 3-1 Installation Process .................. 11 Figure 3-6 Pole Grounding ..................16 Figure 3-7 Grounding Screws ................... 17 List of Tables Table 1-1 Nova442i Interface Description ..............3 Table 1-2 Nova442i LED Indicators ................
-
Page 7: Product Overview
5, 10, 15, or 20MHz bandwidth. Using a Nova442i in DC mode simplifies and streamlines the deployment of split sectors. In addition, HaloB (an embedded EPC option) is available on the Nova442i as part of the base software. The Baicells patented HaloB solution migrates the necessary core network functions to the eNB. -
Page 8: Appearance
Inter operation with all standard LTE Evolved Packet Core (EPC) ú ú Supports TR-069 network management interface ú Lower power consumption, which reduces OPEX, can be powered easily by Baicells compact outdoor smart UPS Appearance The Nova442i eNB appearance is shown in Figure 1-1. Figure 1-1 Nova442i Appearance... -
Page 9: Table 1-1 Nova442I Interface Description
Interface Description Interface Description ETH/POE++ RJ-45 interface (GE), PoE++, complied with IEEE 802.3bt standard Used for power supply and data backhaul/maintenance. The Nova442i interface indicators are described in Table 1-2. Table 1-2 Nova442i LED Indicators Identity Color Status Description Steady On... -
Page 10: Technical Specification
Technical Specification 1.4.1 Technology Item Description Standard LTE TDD RAN (3GPP R15 compliant) TDD UL/DL 1, 2, 6 (with Special subframe configuration 7) Configuration Frequency Band Band40 (2300 MHz – 2400 MHz) Band48 (3550 MHz – 3700 MHz) Channel Bandwidth SC: 5/10/15/20 MHz CA: 40 MHz as maximum aggravated bandwidth Multiplexing... - Page 11 Item Description UL/DL Config 1 2x51 2x14 UL/DL Config 2 2x70 UL/DL Config 6 2x42 2x17 Peak Data Rate 2x20 MHz DL (Mbps) UL (Mbps) (CA) UL/DL Config 1 UL/DL Config 2 UL/DL Config 6 2x10 MHz DL (Mbps) UL (Mbps) UL/DL Config 1 UL/DL Config 2 UL/DL Config 6...
-
Page 12: Modulation Levels (Adaptive)
1.4.4 Modulation Levels (Adaptive) Modulation RSRP (dBm) Coverage Distance (km) Scheme 0 - 4 QPSK -120 ≤ RSRP < -110 9 < D ≤ 12 5- 9 16QAM -110 ≤ RSRP < -100 4 < D ≤9 10 - 19 64QAM -100 ≤RSRP <... -
Page 13: Physical
Item Description Ÿ Horizontal Beam width 360° Vertical Beam width 7.5° Ÿ Ÿ Polarization: ±45° GPS Antenna Internal GPS antenna Antenna Gain 12dBi Power Control UL Open-loop/Closed-loop Power Control, DL Power Allocation (3GPP TS 36.213 compliant) 1.4.7 Physical Item Description Surge Suppression Power Interface Lightning Differential mode: ±10 KA... -
Page 14: Installation Preparation
2. Installation Preparation Support Materials In addition to industry standard tools, you will need the materials described in Table 2-1 during the installation. When selecting an RF antenna, be sure to match the frequency range of the antenna with the eNB. Table 2-1 Support Materials Item Figure... -
Page 15: Installation Environmental Requirements
Percussion drill and hammer Cross screw Cable vice Tape measure some drill heads driver 5mm L-shape allen T7 screwdriver Ladder compass fixed pulley wrench head multimeter Installation Environmental Requirements In addition to network planning, when determining where to place the eNB you need to consider factors such as climate, hydrology, geology, the possibility of earthquakes, reliable electric power, and transportation access. -
Page 16: Lightening & Grounding Protection
Lightening & Grounding Protection You must protect the eNB, antenna, and GPS against lightning. Following are guidelines concerning grounding. Ÿ The yellow-green ground wire must be at least 10mm in diameter. Ÿ In principle, always place the grounding as near as possible to the equipment. Ÿ... -
Page 17: Installation
3. Installation Unpacking Before opening the box, make sure the package is in good condition, undamaged and not wet. During the unpacking, avoid potential damaging impacts from hits or excessive force. Once unpacked, check whether the quantity is consistent with the packing list. Installation Procedure Figure 3-1 provides an overview of the installation process. - Page 18 spring washers and hex nuts. Assemble two clamps on M10 bolts, and fasten with flat washers, spring washers and hex nuts. The reserved distance to the mounting bracket is approximately the diameter of the pole. Hex nuts do not need to be fasten. The mounting bracket assembling is complete.
- Page 19 Put the assembled mounting bracket from the top of the pole. Adjust the position of clamps and fasten hex nuts. Put the eNB from up to down to the bottom, fasten with the M6 captive screws on both sides of the bracket. At last, install the lightning rod. Two installation directions are supported.
-
Page 20: Connect Cable
Connect Cable 3.4.1 Cable Laying Requirements General requirements: Ÿ Bending radius of Ethernet cable and grounding cable: > tripled of the diameter of the cable. Ÿ Bind the cables according the type of the cable, intertwining and crossing are forbidden. Ÿ... -
Page 21: Connect Ground Cable
Tighten the connector of the ETH/POE port in sequence. Connect the other end of the Ethernet cable to the POE port of the PoE adaptor. Connect the LAN port of the PoE adaptor to a LAN switch or a router for maintenance and backhaul. - Page 22 Figure 3-2 Pole Grounding The installation position of the grounding bar shall meet the design requirements. The holding pole and tower body must be connected to the lightning protection network or grounded with a separate lead. The diameter of the grounding wire meets the design requirements. The copper nose must be used for grounding, and the grounding resistance is required to be less than 10 ohms.
-
Page 23: Power On To Check Led Status
downward direction of the feeder, never upward. The grounding electrode of the self-built grounding grid for the outdoor antenna of the tunnel must meet the design requirements. The buried depth of the grounding electrode and the welding quality of the flat iron meet the specification requirements. In principle, the buried depth of the grounding electrode shall not be less than 0.7m. - Page 24 4. FAQ After the device is connected with the power line, the PWR of the device will not be displayed when it is powered on. 1） Maybe the power line is not connected well, and the contact is poor. 2） There is no power in the circuit. 3）...
- Page 25 Terminology & Acronym Acronym Full Name Automatic Neighbor Relations Automatic Repeat Request Carrier Aggregation Component Carriers CSFB Circuit Switched Fallback Dual Carrier Evolved Packet Core network Global Positioning System HARQ Hybrid Automatic Repeat Request IPsec Internet Protocol Security MIMO Multi Input Multi Output Mobility Management Entity MOCN Multi-Operator Core Network...
- Page 26 Acronym Full Name Tracking Area Code...
