Baicells Aurora243 Configuration Manual

Outdoor 5g nr integrated tdd gnb
Hide thumbs Also See for Aurora243:

Advertisement

Quick Links

Download this manual
BSC7048A243
Integrated gNB
Configuration Guide
All rights reserved © Baicells Technologies Co., Ltd.
Document version: 01

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aurora243 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baicells Aurora243

Summary of Contents for Baicells Aurora243

  • Page 1 BSC7048A243 Integrated gNB Configuration Guide Document version: 01 All rights reserved © Baicells Technologies Co., Ltd.
  • Page 2 BaiBBU_QSS_1.1.x. It is a guide that how to configure the device after its installation completes. Copyright Notice Baicells Technologies, Inc., copyrights the information in this document. No part of this document may be reproduced in any form or means without the prior written consent of Baicells Technologies, Inc.

  • Page 3: Table Of Contents

    Contents Configuration Flow ...................... 1 Login Web Client ......................3 Web Client Environmental Requirements ............... 3 Connect Web Client to Base Station ................ 3 Set Up Client Computer .................... 3 Log In .......................... 5 Basic Setting........................ 7 Quck Setting ....................... 7 Configure System Parameter ..................
  • Page 4 Configure Core Network ..................27 Configure Static Route ..................... 27 Configure BTS Parameter ..................29 Configure Management Server ................29 Performance Management ..................29 Configure Synchronization ..................30 Configure Energy Saving ................... 31 License Management ....................31 Certificate Store ....................... 32 Cell Management .....................
  • Page 5 7.8.3 SSB ........................53 7.8.4 UL RSSI Measurement ..................54 7.8.5 DRX ........................54 7.8.6 Voice ......................... 55 7.8.7 GNB ........................55 7.8.8 Multi PLMN ...................... 56 Configure PLMN ....................... 56 7.10 Configure BWP ......................57 7.11 Configure SCS ......................57 7.12 Configure CSI ......................
  • Page 6 Figure 4-5 Diagnostics ....................14 Figure 5-1 Configure WAN/VLAN ................16 Figure 5-2 Add WAN Card ..................17 Figure 5-3 Configure WAN Interface Attribute ............18 Figure 5-4 IPv4 Configuration Parameters..............18 Figure 5-5 IPv6 Configuration Parameters..............19 Figure 5-6 VLAN Configuration Parameters .............. 20 Figure 5-7 Configure IPsec ..................
  • Page 7 Figure 7-15 QoS Setting ..................... 61...
  • Page 8 List of Tables Table 1-1 Data Planning ....................1 Table 2-1 Environmental Requirements of the Client ..........3 Table 2-2 Alarm ......................6 Table 3-1 Quick Setting Parameter Description ............7 Table 4-1 NTP Server Parameter Description............9 Table 4-2 Parameter Description of tcpdump Command ........... 15 Table 5-1 WAN Card Parameter Description .............
  • Page 9 Table 7-12 XN Parameter Description ..............45 Table 7-13 A1 Event Threshold Parameter Description .......... 47 Table 7-14 B1 Event Threshold Parameter Description .......... 49 Table 7-15 Period Measurement Parameter Description ........51 Table 7-16 CU Parameter Description ..............51 Table 7-17 DU Parameter Description ..............

  • Page 10: Configuration Flow

    GUI either locally through the Local Maintenance Terminal (LMT), which is an Ethernet port, or remotely via IP address. You can also use the Baicells Operations and Maintenance Center (OMC) to configure the gNB; this document, however, focuses only on using the gNB GUI.
  • Page 11 Item Parameter Description Parameters Planned by the customer. CellID Planned by the customer. NREF(PointA, SSB) Planned by the customer. Offset To PointA Planned by the customer. Kssb Planned by the customer.

  • Page 12: Login Web Client

    2. Login Web Client Web Client Environmental Requirements Table 2-1 describes the requirements on computer of the client. Table 2-1 Environmental Requirements of the Client Item Description Above Intel Core 1GHz Memory Above 2G RAM Hard disk No less than 100 MB space available Operating system ...

  • Page 13: Figure 2-1 Internet Protocol Version (Tcp/Ipv4)

    Figure 2-1 Internet Protocol Version (TCP/IPV4) Select either “Obtain an IP address automatically” or “Use the following IP address”:  If “Obtain an IP address automatically” selected, go directly to step 7 If “Use the following IP address” selected, follow step 5 ~ step 7 ...

  • Page 14: Log In

    In the command window, execute ping 192.168.150.XXX and check whether the connection between the client computer and the server works. If the ping command fails, contact network engineers to ensure network connectivity. Log In Open a web browser, and enter https://<OAM IP>, as shown in Figure 2-2. Figure 2-2 GUI Login 192.168.150.1 is the initial IP address.

  • Page 15: Table 2-2 Alarm

    NOTE: The menus and information may vary by product type or software version. The homepage displays the navigation pane on the left, and shows the window for the first menu: Basic Setting > Basic Info. This window is like a dashboard for the device.

  • Page 16: Basic Setting

    Quck Setting The quick settings determine important RF parameters, as well as connectivity to Baicells ColudCore Evolved Packet Core (EPC). These parameters need to be planned in advance in the network planning stage. In the navigation column in the left, select “Basic Setting > Quick Setting” to enter the quick setting page, as shown in Figure 3-1.
  • Page 17 Parameter Description 30kHz in this version. DL CarrierBandWidth(RB) Downlink carrier bandwidth. UL SubCarrierSpacing Uplink subcarrier spacing. The eNB supports 30kHz in this version. UL CarrierBandWidth(RB) Uplink carrier bandwidth. Power Modify Transmit power. Range from 0 to 43dBm. Click “Save” to complete the quick settings for the gNB.

  • Page 18: Configure System Parameter

    4. Configure System Parameter Configure NTP This page includes the time zone and the NTP configuration, which are configured according to the actual needs. If the NTP is used by the gNB as an external clock source, up to five NTP servers are supported, where one for master NTP service and the others for backup.

  • Page 19: Configure Log

    Click “Save” to complete the NTP server configuration. Configure Log In the navigation column on the left, select “System > Log” to enter the log level setting page, as shown in Figure 4-2. Figure 4-2 Log Level Setting The gNB supports the log level setting for Media Access Control (MAC) log, Radio Link Control (RLC) log and RLCL.

  • Page 20: Firmware Upgrade

    Caution: Firmware upgrade may lead to the damage of the eNB file, contact the support engineer before upgrade. If necessary, the vendor will provide the technical support. 4.3.1 Firmware Upgrade In the navigation column on the left, select “System > Upgrade” to enter the upgrade management page, as shown in Figure 4-3.

  • Page 21: Rollback

    In the pop-up window click “PROCEED”. In the “Basic Setting > Basic Info” page, the upgraded version will be displayed in “Software Version". 4.3.2 Rollback Only one rollback operation is allowed for each upgrade. Under the rollback permission of the BBU, the software can roll back to the version before upgrade. After the rollback, a new rollback will not be permitted until an upgrade has taken place.

  • Page 22: Backup Current Configuration

    Figure 4-4 System Backup 4.4.1 Backup Current Configuration Click “Get Backup Files”. In the pop-up download dialog box, select the file path to save the current configuration file to the local computer. 4.4.2 Backup Log Files Click “Get Log Files”. In the pop-up download dialog box, select the file path to save the log files to the local computer.

  • Page 23: Restore Default Configuration

    4.4.4 Restore Default Configuration Attention: After the restore operation, the eNB will reboot immediately. Be careful to operate the “Restore Default Configuration” restore. It will disrupt the current service. Click “Restore Default Configuration”. In the pop-up download dialog box click “OK”, the base station will reboot immediately.

  • Page 24: Reboot

    Table 4-2 Table 4-2 Parameter Description of tcpdump Command Parameter Description Method of Diagnostics The current version supports tcpdump command. Command Tcpdump command Count of captured packetsThe number of captured packets. Click “Start” to run the tcpdump command. Click “Stop” to stop running. Click “Get File”...

  • Page 25: Configure Network Interface

    The WAN interface is an external communication portal (Internet connection) the gNB’s NMS and the core network. The gNB’s NMS may be the Baicells Operation and Maintenance Center (OMC) or other NMS. The only option for the Interface name field is WAN.

  • Page 26: Figure 5-2 Add Wan Card

    Figure 5-2 Add WAN Card Input parameters of the WAN card, as shown in Table 5-1. Table 5-1 WAN Card Parameter Description Parameter Description Index Index. Generated automatically. Enable Enable or disable the port. Name Name UserLabel User label Max Bit Rate Select maximum bit rate of the port from the drop-down list.

  • Page 27: Figure 5-3 Configure Wan Interface Attribute

    Figure 5-3 Configure WAN Interface Attribute Configure IPv4, IPv6, or VLAN parameters based on the actual network deployment. IPv4  Click on “WAN IPv4 table” zone to display the IPv4 configuration parameters, as shown in Figure 5-4 Figure 5-4 IPv4 Configuration Parameters The description of IPv4 configuration parameters is shown in Table 5-2.

  • Page 28: Figure 5-5 Ipv6 Configuration Parameters

    Parameter Description usage of the port.    Ng/Xn    S1/X2     Other When “Addressing Type” is set to “static”, the parameter displays. IP address of the WAN interface. Default When “Addressing Type” is set to “static”, the parameter Gateway displays.

  • Page 29: Figure 5-6 Vlan Configuration Parameters

    Table 5-3 IPv6 Parameter Description Parameter Description Addressing The interface protocol used by WAN interface, include: Type  DHCPv6: If DHCP is selected, no other parameter needs to be configured.  Static: If Static is selected, the IP address, prefix length, and gateway should be configured.

  • Page 30: Configure Ipsec

    The description of VLAN configuration parameters is shown in Table 5-4. Table 5-4 VLAN Parameter Description Parameter Description Name VLAN name. VLAN ID Enable Enable or disable the VLAN.  0: Disable  1: Enable Click “Save” to complete the WAN and VLAN configuration. Configure IPsec The security gateway (SeGW) in the network can provide security protocol in the network layer to ensure the safety for message transmission.

  • Page 31: Figure 5-8 Edit Ipsec Tunnel

    Select enable or disable the IPsec function. The IPsec function is enabled by default. If the IPsec function is enabled, click to add a IPsec tunnel. In “IPsec Tunnel List” area, click to enter the edit dialog box, as shown in Figure 5-8.

  • Page 32: Table 5-6 Advanced Parameter Description Of Ipsec Tunnel Mode

    Parameter Description on the security gateway side. Right Subnet IP address of the remote subnet, which must be consistent with the security gateway side. Message within this address range will be packed as a tunnel. Right Id Identification of the server end (0-48 digits string). It must be consistent with the security gateway side.
  • Page 33 Parameter Description IKE DH Group IKE Diffie-Hellman (DF) key computation, or exponential key agreement, to be used between two entities.  MODP768  MODP1024  MODP1536  MODP2048  MODP4096 IKE Authentication Authentication algorithm  SHA1  SHA1_160 SHA256_96  ...

  • Page 34: Configure Dscp

    Parameter Description  Clear Hold   Restart Dpddelay Time interval for sending the DPD detection message. Format: Seconds, Minutes, Hours or Days. Left Interface The interface on the eNB side. Input strong wan configuration parameters, as shown in Table 5-7. Table 5-7 Strong Wan Parameter Description Parameter Description...

  • Page 35: Figure 5-9 Configure Dscp

    Figure 5-9 Configure DSCP Click to display DSCP adding window as shown in Figure 5-10. Figure 5-10 Add a DSCP Input DSCP parameters, as shown in Table 5-8.

  • Page 36: Configure Core Network

    Table 5-8 DSCP Parameter Description Parameter Description DSCP DSCP code, which is used to differentiate the priority level. Range from 0 to 63 integer. Vlan Priority Vlan priority. Range from 0 to 7 integer. Click “Save” to complete the DSCP setting. On the lower of the page, you can specify DSCP value and VLAN priority for NGAP, X2AP, F1AP, XNAP and OAM.

  • Page 37: Figure 5-12 Configure Static Route

    Figure 5-12 Configure Static Route Input the configuration parameters of static route, which are given in Table 5-9. Table 5-9 Static Route Parameter Description Parameter Description IP Address Version  IPv4  IPv6 Port Name Port Name Destination Network The destination IP address. NOTE: The target IP address must reachable from the original IP address of WAN interface or VLAN source port.

  • Page 38: Configure Bts Parameter

    For the Network Management System (NMS), an operator has the option to use the Baicells Cloudcore OMC, a local OMC, or other their own management server. After the NMS settings, you can login the NMS to check whether the gNBs have been added or not.

  • Page 39: Configure Synchronization

    Figure 6-2 Performance Management Input the performance management parameters, which descriptions are given in in Table 6-2. Table 6-2 Performance Management Parameter Description Parameter Description Enable or disable the performance management. ON: Enable OFF: Disable Alise The alise. http://localhost.net Username Username Password Password...

  • Page 40: Configure Energy Saving

    In the left navigation column, select “BTS Setting > Sync Setting” to enter the synchronization configuration page, as shown in Figure 6-3. Figure 6-3 Synchronization Mode Setting Select GPS source.   GLONASS  BEIDOU  GALILEO  QZSS Input PPS time offset. Range is from 0 to 5,000,000ns. Click “Save”...

  • Page 41: Certificate Store

    Figure 6-4 License Management Remain Time Indicates the remaining days of the License. If 0 is displayed, apply for a License and upload it to update it as soon as possible. Otherwise, the cell cannot be activated or user access is restricted. Select the License file from the local computer.

  • Page 42: Figure 6-6 Cell Management

    Figure 6-5 Cell Management This version supports one cell.

  • Page 43: Configure Nr Parameter

    7. Configure NR Parameter Configure LTE Neighbor Frequency and Cell In the left navigation column, select “NR Setting > LTE Freq/Cell” to enter the LTE neighbor frequency and cell configuration page, as shown in Figure 7-1. Figure 7-1 LTE Neighbor Frequency/Cell Settings Users can add, modify, and delete the LTE neighbor frequency and cell.

  • Page 44: Table 7-2 Lte Neighbor Cell Parameter Description

    Parameter Description neighboring gNBs, as determined by the received signal level at the UE. If the received signal level is better from a neighboring gNB by at least this amount of difference in dB, the UE will reselect the other cell. The range is -24 to +24.

  • Page 45: Configure Nr Neighbor Frequency And Cell

    Parameter Description PhyCellID Physical Cell Identifier (PCI) of the neighbor cell. Frequency offset this neighbor cell. Indicates the difference in signal level between the serving and this neighboring eNB, as determined by the received signal level at the UE. If QOffset the received signal level is better from a neighboring eNB by at least this amount of difference in dB, the UE will reselect...

  • Page 46: Figure 7-2 Nr Neighbor Frequency/Cell Settings

    Figure 7-2 NR Neighbor Frequency/Cell Settings Users can add, modify, and delete the NR neighbor frequency and cell. Intra Frequency Measurement In the IntraFREQ Measurement list, click to enter the page for adding an intra frequency measurement, the parameter descriptions are given in Table 7-3. Table 7-3 Intra Frequency Measurement Parameter Description Parameter Description...

  • Page 47: Table 7-4 Inter Frequency Measurement Parameter Description

    Parameter Description SSBFrequency The frequency of SSB. Range is from 0 to 3279165. SubcarrierSpacing The space between subcarriers. The period of (SSB-based RRM Measurement Timing Configuration) SMTC.   sf10 SmtcPeriodicity  sf20  sf40  sf80 sf160  SmtcOffset The offset of SMTC.

  • Page 48: Table 7-5 Neighbor Cell Parameter Description

    Parameter Description SSBlocksConsolidationS The consolidation of SSB blocks of Signal to Interference plus Noise Ratio (SINR). Range is from 0 to 127. This parameter indicates the signal quality of a cell in NR NrofSSBlocksToAverage measurement of SSB. Range is from 2 to 16. RsrpOffsetSSB The SSB offset of RSRP.

  • Page 49: Configure Sib

    Parameter Description dB, the UE will reselect this cell. Range is +24 to -24. A typical value is 0dB. Cell minimum received level offset. This parameter represents the cell’s minimum received level offset. It is QRxLevMinOffsetCell used only when the UE resides in the VPLMN and cell selection is triggered due to periodic searches for high-priority PLMNS.

  • Page 50: Figure 7-3 Sib Setting

    Figure 7-3 SIB Setting The gNB supports SIB1 to SIB5.  SIB1 The parameter description of SIB1 is shown in Table 7-6. Table 7-6 SIB1 Parameter Description Parameter Description QRxLevMinSIB1 The minimum received level of SIB1. Range is from -70 to -22. Qqualminoffset Cell minimum received signal quality offset.

  • Page 51: Table 7-7 Sib2 Parameter Description

    Table 7-7 SIB2 Parameter Description Parameter Description Enable Enable or disable SIB2. Qhyst Delay time for re-selection. General the value of the parameter is 2. Range is from 0 to15. This parameter will overestimate the signal strength of the serving cell to delay the cell reselection.

  • Page 52: Configure Anr

     SIB5 The parameter description of SIB1 is shown in Table 7-10. Table 7-10 SIB5 Parameter Description Parameter Description Enable Enable or disable SIB5. SIB5 valueTag The tag of SIB5 value. Range is from 0 to 31. Configure ANR In the left navigation column, select “NR Setting >ANR” to enter the ANR configuration page, as shown in Figure 7-4.

  • Page 53: Configure Xn

    Parameter Description Enable or disable the EUTRAN. EUTRANEnable ON: Enable   OFF: Disable Enable or disable the BiNR cell. BiNRCellEnable  ON: Enable  OFF: Disable MR trigger type. MRTriggerType  Event  Period AbsoluteThreshold Absolute threshold. Range is from 0 to 127. RelativeThreshold Relative threshold.

  • Page 54: Configure Pci

    Figure 7-5 XN Settings In the XN list, click to pop up the XN configuration parameters. Input XN parameters, the parameter description is shown in Table 7-12. Table 7-12 XN Parameter Description Parameter Description PLMNID PLMN ID RemoteAddress The remote IP address. Enable or disable the XN link.

  • Page 55: Configure Mobility Parameter

    Figure 7-6 PCI Setting Select whether enable the PCI conflict detection function. Click “Save” to complete the PCI setting. Configure Mobility Parameter In the left navigation column, select “NR Setting > Mobility Parameter” to enter the mobility parameter configuration page. The Mobility Parameter menu pertains to how roaming UE sessions are handled between different gNBs in the same service area.

  • Page 56: Table 7-13 A1 Event Threshold Parameter Description

    Ms+Hys<Thresh (4.2) Ms indicates the measurement results of the serving cell with no offset. Hys indicates the hysteresis parameter of the event. Thresh indicates the preset threshold. In the A1 list, click to display A1 event configuration parameters, which are shown in Table 7-13.

  • Page 57: A2 Event Threshold

    Parameter Description 2: Inter-RAT EUTRA measurement. The customized measurement event is from 10. Report Amount The number of report. Range is from 1 to 100. MaxNrofRSIndexToRe The maximum number of RS measurement report. Range port is from 1 to 32. Report Interval The report interval of A1 event triggering report.

  • Page 58: A4 Event Threshold

    7.7.4 A4 Event Threshold The A4 event is triggered when the neighbor cell becomes better than the serving cell by as much as the relative threshold value. A4 event is used to the handover based on coverage of intra-frequency and inter-frequency.. In the A4 list, click to display A4 event configuration parameters.

  • Page 59: B2 Event Threshold

    Parameter Description B1 Threshold1 EUTRA The SINR threshold value for triggering B1 event. SINR Range is from 0 to 127. This parameter Refers to the hysteresis (historical records) of the handover measurement event. The value is used to avoid the frequent triggering of cell handover evaluation due to the fluctuation in wireless signals.

  • Page 60: Period Measurement Parameter

    7.7.8 Period Measurement Parameter In the Period Measure list, click to display period measurement configuration parameters, which are shown in Table 7-15. Table 7-15 Period Measurement Parameter Description Parameter Description Report Quantity The RS measurement report of the V1 event, including RSRP, RSRQ, and SINR.

  • Page 61: Table 7-17 Du Parameter Description

    Parameter Description This parameter is used to indicate that the Pcell receives the NR N311 maximum continuous “in-sync” message from the bottom layer. RRC timer. When the gNB receives the RRCResumeRequest NR T319 message, the timer starts up. F1ap Local IP The CU IP address in control plane of F1 interface.

  • Page 62: Ssb

    Parameter Description PAT2 of Downlink Subframe ratio. The special time slot downlink symbol Symbols configuration of PAT2. Range is from 0 to 13. PAT2 of Uplink Subframe ratio. The uplink time slot configuration of PAT1. Slots Range is from 0 to 320. PAT2 of Uplink Subframe ratio.

  • Page 63: Ul Rssi Measurement

    Parameter Description The frequency point of SSB. Range is from 0 to SSB Absolute Freq 3279165. The reserved resource of SSB. SsbResourceReserved  ON: Enabled  OFF: Disabled Click “Save” to complete the SSB setting. 7.8.4 UL RSSI Measurement NOTE: In this software version, UL RSSI does not be supported. 7.8.5 DRX Click + in the front of “DRX”...

  • Page 64: Voice

    Parameter Description ShortDRXCycle Short DRX period. The timer of DRX short period. Range is from 0 to 16. If the value is set to 1, it means 1 * ShortDRXCycle.  ShortCycleTimer If the value is set to 1,  2 * ShortDRXCycle And so forth.

  • Page 65: Multi Plmn

    7.8.8 Multi PLMN Click + in the front of “Multi PLMN” to display multi PLMN configuration parameters. Whether enable multi PLMN. Click “Save” to complete the multi PLMN setting. Configure PLMN In the left navigation column, select “NR Setting > PLMN” to enter the PLMN configuration page, as shown in Figure 7-7.

  • Page 66: Configure Bwp

    7.10 Configure BWP NOTE: In this software version, BWP does not be supported. 7.11 Configure SCS In the left navigation column, select “NR Setting > SCS” to enter the Sub-carrier Space (SCS) configuration page, as shown in Figure 7-8. Figure 7-8 SCS Setting In the DL SCS list, click to display the downlink SCS parameters, which description is shown in Table 7-23.

  • Page 67: Configure Csi

    7.12 Configure CSI In the left navigation column, select “NR Setting > CSI” to enter the CSI configuration page, as shown in Figure 7-9. Figure 7-9 CSI Setting Click to display CSI configuration parameters, the configuration parameter description is shown in Table 7-24. Table 7-24 CSI Parameter Description Parameter Description...

  • Page 68: Configure Srs

    Parameter Description Format Ind  widebandPMI subbandPMI  Click “Save” to complete the CSI setting. 7.13 Configure SRS NOTE: In this software version, SRS does not be supported. 7.14 Configure PUSCH In the left navigation column, select “NR Setting > PUSCH” to enter the PUSCH page, as shown in Figure 7-10.

  • Page 69: Configure Pucch

    Figure 7-11 PDSCH Setting Input PDSCH configuration parameters, which description is shown in Table 7-25. Table 7-25 PDSCH Parameter Description Parameter Description Enable or disable the power control function. Power Control ON: Enable   OFF: Disable Power Control Value The start value of power control.

  • Page 70: Configure Qos

    Parameter Description  ON: Enable OFF: Disable  Enable or disable Clpc PUCCH SINR. ClpcPucchSinrEnable  ON: Enable  OFF: Disable Enable or disable Clpc PUCCH BLER. ClpcPucchBlerEnable  ON: Enable  OFF: Disable Click “Save” to complete the PUCCH setting. 7.17 Configure QoS In the left navigation column, select “NR Setting >...
  • Page 71 Parameter Description Enable Enable or disable QoS function. MappingDrbIndex Index Range is from 1 to 255.  Type  Non-GBR Priority Priority Range is from 1 to 16. MinBr MinBr IsDefault Whether the QoS is default. UeInactivityTimerConifg UE inactivity Timer. TReordering PDCP TReorderingPdcp Range is from 0 to 35.

  • Page 72: Configure Testmac

    Parameter Description ShortDrxCycle Short DRX cycle. ShortDrxCycleTimer Short DRX cycle timer. DrbInactivityTimerConfig DRB inactivity timer. In the SST list, click to display the SST configuration parameters, which description is shown in Table 7-28. Table 7-28 SST Parameter Description Parameter Description Enable or disable SST.

  • Page 73: Appendix A Terminology & Acronym

    Appendix A Terminology & Acronym Acronym Full Name Above Ground Level Address Resolution Protocol CBRS Citizen Broadband Radio Service CBRD CBRS Service Device CHAP Challenge Handshake Authentication Protocol Certified Professional Installer CSFB Circuit Switched Fallback DHCP Dynamic Host Configuration Protocol Domain Name System Discontinuous Reception DSCP...
  • Page 74 PDSCH Physical Downlink Shared Channel PLMN Public Land Mobile Network PPPOE Point to Point Protocol over Ethernet PRACH Physical Random Access Channel Physical Resource Block PUCCH Physical Uplink Control Channel PUSCH Physical Uplink Shared Channel Radio Resource Control RSRP Reference Signal Receiving Power RSRQ Reference Signal Receiving Quality RSSI...

  • Page 75: Appendix Bfcc Compliance

    Appendix B FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
