- Page 1 ATOM OD06 - EG7010C-M11 USER Manual All rights reserved © Baicells Technologies Co., Ltd.
-
Page 2: Shipping List
1. Shipping List Make sure you have got the following parts: EG7010C Quick Guide PoE Adapter Power Cord Standard Mounting Kits Optional Mounting Kits... -
Page 3: Hardware Introduction
2. Hardware Introduction Indicators Identity Description Color Status Description Yellow Reserved. Steady On Reserved. Blanking Reserved. Network state LTE disconnected. Blue Indicator Steady On LTE connected. card Yellow Steady On The SIM card is normal. status Blanking The SIM card is abnormal or not indicator inserted. - Page 4 Identity Description Color Status Description connection state Blanking Scanning the LTE network signal strength The CPE is authenticating. CPE is getting IP address from the LTE network. Interface and Buttons Interface & Button Description Connected to the PoE Power Adapter Support SD card Support 1.8V/3.0V USIM 2FF RESET...
-
Page 5: Support Materials
3. Installation Guide Support Materials Before installation, prepare the following support materials accordingly, as given below: Item Description Ethernet cable Outdoor Shield CAT5E Shorter than 330 feet Ground wire 16mm² yellow-green wire Install USIM Card and Cables (1) Screw the screw on the waterproof (2) Insert the USIM card to the USIM cover, and open the waterproof cover slot. -
Page 6: Install On Wall
Install on Wall Slipping the bracket from the CPE. Fit the CPE on the wall, and mark the drilling locations. Drill four 10mm diameter and 70mm depth holes in the wall by following the marked locations. Check the up/down direction of the bracket, and then fix it on wall using M5 tapping screws. -
Page 7: Install On Pole
Install on Pole Round an anti-slip rubber on the pole. Fix the bracket using the hoop. 3. Install the CPE to the bracket and fasten the screw. Grounding The EG7010C-M11 must be grounding, please contact professional person to operation. Using grounding cable, connect the grounding cable to the ground row... -
Page 8: Configuration Guide
4. Configuration Guide 4.1 Login The CPE manages, configures, and maintains the device by web management page. The steps to log in are as follows: In the address column of browser, type in http://192.168.150.1, then press “Enter”: Enter the user name and password, click "LOGIN". After password authentication, you can log on to the web management page. - Page 9 SAS Settings, as shown below:...
-
Page 10: Basic Specifications
5. Specifications Basic Specifications Item Description UE-Category 3GPP R10, CAT 6/7 USIM Slot 1.8V/3.0V USIM 2FF 1 RJ45, LAN, 10/100/1000 auto-sensing, auto-MDX, Ethernet Port Input: Universal range 100V~240V AC Power Supply Output: PoE (24V DC, 0.5A) Tactile button. Long press over 10s to restore the Reset Button factory settings LED Indicators... - Page 11 Modulation QPSK, 16QAM Receive Sensitivity -94dBm @ QPSK,20MHz, 25°C MAX Output Power 26dBm Antenna Type Internal directional-antenna Antenna Gain 14dBi@3.xGHz, 2 Ports Polarization ±45° Antenna Efficiency >70% ≤-25dB Isolation ≤2 VSWR Horizontal Beam Width (3dB) 60±3°@3.xGHz, 2 Ports Vertical Beam Width (3dB) 25±5°@3.xGHz, 2 Ports SW Specifications Item...
-
Page 12: Environmental Specifications
Port forwarding Port Trigger IP/MAC/URL Filter Access Control Firewall Block Port Scanner / SYN Flood SPI Filter TR069 Network Management SNMP TCPDump Ping Diagnostics Trace route LTE Status/Connection Time/System Up Time ... -
Page 13: Regulatory Compliance
6. Regulatory Compliance FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
