Parameter List

Par
Level 1 parameters
01 Minimum set speed (Hz)
02 Maximum set speed (Hz)
03 Acceleration rate (s/100Hz)
04 Deceleration rate (s/100Hz)
05 Drive configuration
06 Motor rated current (A)
07 Motor rated speed (rpm)
08 Motor rated voltage (V)
Motor power factor (cos ϕ)
09
10 Parameter access
Level 2 parameters
11 Start/Stop logic select
12 Brake controller enable
13
Not used
14
15 Jog reference (Hz)
16 Analog input 1 mode (mA)
17 Enable negative preset speeds
18 Preset speed 1 (Hz)
19 Preset speed 2 (Hz)
20 Preset speed 3 (Hz)
21 Preset speed 4 (Hz)
22 Load display units
23 Speed display units
24 Customer defined scaling
25 User security code
26 Not used
27 Power up keypad reference
28 Parameter cloning
29 Load defaults
30 Ramp mode select
31 Stop mode select
32 Dynamic V to f select
33 Catch a spinning motor select
34 Terminal B7 mode select
35 Digital output control (terminal B3)
36 Analog output control (terminal B1)
37 Maximum switching frequency (kHz)
38 Autotune
39 Motor rated frequency (Hz)
40 Number of motor poles
41 Voltage mode select
42 Low frequency voltage boost (%)
43 Serial communications baud rate
44 Serial comms address
45 Software version
46 Brake release current threshold (%)
47 Brake apply current threshold (%)
48 Brake release frequency (Hz)
49 Brake apply frequency (Hz)
50 Pre-brake release delay (s)
51 Post brake release delay (s)
55 Last trip
56 Trip before Pr 55
57 Trip before Pr 56
VFD67 Size E to F Getting Started Guide
Issue Number: 1
Electrical Keypad and
Installation Display
Description
www.johnsoncontrols.com
Quick Start
Parameters Diagnostics
Commissioning
Default
0.0
60.0
33.0
33.0
PAd
Drive rating
1800
230/460/575/690
0.85
L1
4
diS
1.5
4-.20
OFF
0.0
0.0
0.0
0.0
Ld
Fr
1.000
0
0
no
no
1
1
OFF
0
dig
n=0
Fr
3
0
60.0
Auto
Fd
1.0
19.2
1
50
10
1.0
2.0
1.0
1.0
0
0
0
