If the full load speed of the motor is above 9999rpm, enter a value of 0 in Pr 07. This will disable slip compensation as values >9999 cannot be
entered into this parameter.
No Function
08 Motor rated voltage
Enter the motor rated voltage (taken from the motor name plate).
This is the voltage applied to the motor at base frequency.
NOTE
If the motor is not a standard 50 or 60Hz motor, see Pr 39 on page 34 and adjust accordingly.
No Function
09 Motor power factor
Enter the motor rated power factor cos ϕ (taken from the motor name plate).
NOTE
The power factor value could be automatically changed after a rotating autotune. See Pr 38 on page 33.
No Function
10 Parameter access
L1: Level 1 access - only the first 10 parameters can be accessed
L2: Level 2 access - All parameters from 01 to 60 can be accessed
L3: Level 3 access - All parameters from 01 to 95 can be accessed
LoC: Used to lock a security code in the drive. See section 5.6 Security codes on page 24 for further details.
6.2

Parameter descriptions - Level 2

No Function
11 Start/Stop logic select
Pr 11 Terminal B4
0 Enable
1 /Stop
2 Enable
3 /Stop
4 /Stop
5 User programmable
6 User Programmable User Programmable User Programmable
NOTE
A change to Pr 11 is set by pressing the
change to take place. If Pr 11 is changed while the drive is running, when the
change back to its previous value.
No Function
12 Brake controller enable
diS: Mechanical brake software disabled
rEL: Mechanical brake software enabled. Brake control via relay T5 & T6. The digital output on terminal B3 is automatically programmed as a drive
ok output.
d IO: Mechanical brake software enabled. Brake control via digital output B3. The relay outputs on terminals T5 and T6 are automatically
programmed as a drive ok output.
USEr: Mechanical brake software enabled. Brake control to be programmed by user. The relay and digital output are not programmed. The user
should programme the brake control to either the digital output or relay. The output not programmed to the brake control can be programmed
to indicate the required signal.
NOTE NOTE
A change to Pr 12 is set by pressing the
change to take place. If Pr 12 is changed while the drive is running, when the
change back to its previous value.
VFD67 Size E to F Getting Started Guide
Issue Number: 1
Electrical Keypad and
Installation Display
Range
0 to 240V, 0 to 480V,
0 to 575V, 0 to 690V
Range
0 to 1
Range
L1, L2, L3, LoC
Range
0 to 6
Terminal B5 Terminal B6
Run Forward Run Reverse
Run Forward Run Reverse
Run Forward / Reverse
Run Forward / Reverse
Run Jog
Run Forward Run Reverse
MODE key on exit from parameter edit mode. The drive must be disabled, stopped or tripped for a
M
Range
diS, rEL, d IO, USEr
MODE key on exit from parameter edit mode. The drive must be disabled, stopped or tripped for a
M
www.johnsoncontrols.com
Quick Start
Parameters Diagnostics
Commissioning
Defaults Type
230/460/575/690 RW
Defaults Type
0.85 RW
Defaults Type
L1 RW
Defaults Type
4 RW
Latching
No
Yes
No
Yes
Yes
No
User Programmable
MODE key is pressed on exit from parameter edit mode, Pr 11 will
M
Defaults Type
diS RW
MODE key is pressed on exit from parameter edit mode, Pr 12 will
M
