3.5

Electrical terminals

Figure 3-15 Location of power and ground terminals
SmartStick slot
Serial
communications
port connector
Ground
connections
8mm AF
3.5.1 Terminal sizes and torque settings
To avoid a fire hazard and maintain validity of the UL Listing,
adhere to the specified tightening torques for the power and
ground terminals. Refer to the following tables.
WARNING
Table 3-3 Drive control and relay terminal data
Model Connection type
All Spring terminals
Table 3-4 Drive power terminal data
Model
AC terminals
size
Plug-in terminal Terminal block (M5
E block 1.5Nm
(1.1 lb ft)
Terminal block (M6 screws) 2.5Nm
F
(1.8 lb ft)
Torque tolerance
VFD67 Size E to F Getting Started Guide
Issue Number: 1
Electrical Keypad and
Installation Display
Display
Control terminals
Power terminals
Ground
connections
8mm AF
DC and braking
Ground terminals
terminals
M5 stud 4.0Nm
screws) 1.5Nm
(2.9 lb ft)
(1.1 lb ft)
6.0Nm
(4.4 lb ft)
±10%
www.johnsoncontrols.com
Quick Start
Parameters Diagnostics
Commissioning
± DC Bus /
Braking
Pozi Pozi Pozi T20
Pz 2 Pz 2 Pz 2
Torx
E
Pozi Pozi
Pz 2 Pz 2
AC supply /
motor
connections
UL Listing
Parameter List
Information
± DC Bus /
Braking
Pozi Pozi
Pz 3 Pz 2
Internal
EMC
filter
F
AC supply /
Pozi Pozi
motor
Pz 3 Pz 2
connections
Technical
specifications
Pozi T20
Pz 2
Torx
Internal
EMC
filter
