In all of the settings below, the status relay is set up as a drive ok relay:
T5
OK
Fault
T6
Configuration
AI.AV
Voltage and current input
AV.Pr
Voltage input and 3 preset speeds
AI.Pr
Current input and 3 preset speeds
Pr
4 preset speeds
PAd
Keypad control
E.Pot
Electronic motorized potentiometer control
tor
Torque control operation
Pid
PID control
HVAC
Fan and pump control
Figure 6-1 Pr 05 = AI.AV (current or voltage input)
Remote speed
reference input
10k
(2kmin)
_
+
V
Terminal B7 open: Local voltage speed reference (A2) selected
Terminal B7 closed: Remote current speed reference (A1) selected
Figure 6-2 Pr 05 = AV.Pr (voltage input and 3 presets)
10k
(2kmin)
_
+
V
T4
B7
Reference selected
0
0
Preset 1
0
1
Preset 2
1
0
Preset 3
1
1
Preset 4
26
Electrical
Keypad and
Parameters
Installation
Display
Description
T1
0V
Remote current speed
T2
reference input (A1)
T3
+10V reference output
Local voltage speed
T4
reference input (A2)
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
Local (A2)/Remote (A1)
B7
speed reference select
T1
0V
Local voltage speed
T2
reference input (A1)
T3
+10V reference output
T4
Reference select
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
B7
Reference select
www.johnsoncontrols.com
Quick Start
Diagnostics
Commissioning
T4
B7
Reference selected
0
0
A1
0
1
Preset 2
1
0
Preset 3
1
1
Preset 4
Figure 6-3 Pr 05 = AI.Pr (current input and 3 presets)
Remote speed
reference input
_
+
V
T4
B7
Reference selected
0
0
A1
0
1
Preset 2
1
0
Preset 3
1
1
Preset 4
Figure 6-4 Pr 05 = Pr (4 presets)
_
+
V
VFD67 Size E to F Getting Started Guide
UL Listing
Technical
Parameter List
Information
specifications
T1
0V
Remote current speed
T2
reference input (A1)
T3
+10V reference output
T4
Reference select
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
B7
Reference select
T1
0V
T2
Not used
T3
+10V reference output
T4
Reference select
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
B7
Reference select
