Technical specifications

Model
Drive voltage rating
Output Voltage/Output frequency
Switching frequency
Duty
Overload limit
Acceleration/Deceleration
Start/Stop
Motor cable lengths
Ambient temperature
Storage temperature
Altitude
Humidity
Storage humidity
Enclosure
Approvals
Dimensions
Weight
44
Electrical Keypad and
Parameters
Installation Display
VFD67
230Vac, 460Vac, 575Vac @ 60Hz (230Vac, 400Vac, 575Vac @ 50Hz)
230 Vac, 460Vac, 575Vac @ 60Hz (230Vac, 400Vac, 575Vac @ 50Hz)
3kHz, 6kHz, 12kHz
Normal, Heavy
Normal Duty: 110% overload current for 215s
Heavy Duty:150% overload current for 60s
0 to 3200.0 s/100Hz
Terminal control / keypad control
≤
200m
Ambient temperature operating range:
0°C to 50°C (32°F to 122°F).
Output current derating must be applied at ambient temperatures >40°C (104°F).
Minimum temperature at power-up:
-15°C (5°F), the supply must be cycled when the drive has warmed up to 0°C (32°F).
Cooling method: Forced convection
-40 (-40°F) to +50°C (122°F) for long term storage, or to +70°C (158°F) for short term storage.
Altitude range: 0 to 3,000m (9,900 ft), subject to the following conditions:
1,000m to 3,000m (3,300 ft to 9,900 ft) above sea level: de-rate the maximum output current from the
specified figure by 1% per 100m (330 ft) above 1,000m (3,300 ft)
For example at 3,000m (9,900ft) the output current of the drive would have to be de-rated by 20%.
Maximum relative humidity 95% non-condensing at 40°C (104°F).
Maximum relative humidity 93%, 40°C, 4 days.
NEMA1, UL type 1
CE approval, C Tick approval, Ul / cUL approval (The JCI file number is E244421)
See section 3.2 Mounting methods on page 12
Size E: 15.4 lb (7 kg)
Size F: 33.1 lb (15 kg)
