FORM 145.13-NO2
ISSUE DATE: 1/22/2020

INPUT/OUTPUT

Jumper is set to 0–10VDC for
DSH/DSV C-gen
Jumper required between 10, 11

FIGURE 7 - INPUT/OUTPUT DIAGRAM

PARAMETER TABLES

In the parameter menu, set the following parameters
listed in the following parameters tables to operate the
VFD controller correctly. For troubleshooting, check
that the parameters match.

SECTION 2 - OPERATION

DISPLAY

In AUTO MODE, the following parameters display on
control display:
1. 30–60Hz is the output frequency to the motor. The
2. 0.0–Nominal Motor Amps. The maximum amps
3. 0.0–5.0 "WC is the actual reading from the pres-
4. The setpoint value is displayed in the upper-right
minimum factory set frequency allowed is 30 Hz.
draw is factory set, and is set to nominal amp
draw of motor used.
sure transducer.
corner. Values range from 0% to 100%. That is
the actual setpoint for the controller. The setpoint
can be 0%, which is 0.0 "WC or 100%, which is
5.0"WC.
2
11
