Seagull Models PERCIVAL MEW GULL Assembly Manual page 8

PERCIVAL MEW GULL
2) Insert the 90º bend of one main gear
wire and support mounting block into the pre-
drilled hole in one mounting slot.
1.5mm.
M3 x 15mm.
Wheel.
Axle.
Wheel collar.
M8.
Landing gear.
8
.
Remove
covering.
Instruction Manual.
Wheel collar.
.
M3 x 10mm
M4 x 6mm.
Axle.
M3 x 10mm.
