. Instruction Manual.
PERCIVAL MEW GULL
Carefully slide the two wing halves together
and firmly press them together, allowing the
excess epoxy to run out. There should not be
any gap in the wing halves. Use rubbing
alcohol and a paper tower to clean up any
excess epoxy.
Apply masking tape at the wing join to hold
the wing halves together securely.
INSTALLING VERITICAL FIN.
Masking tape.
1) Remove the covering as picture shown
below.
3) Peel off the backing from the self adhe-
sive covering strip. Apply the strip to the centre
section of the wing starting from the bottom
trailing edge. Wrap the strip all the way around
the wing until it meets the trailing edge again.
Trim off any excess strip.
MOUNTING THE TAIL WHEEL.
Hinge.
See pictures below.
Masking tape.
Cut.
M3 x 25mm.
Remove the covering.
M3 x 25mm.
Epoxy.
14
