Johnson Controls FRICK QUANTUM LX AcuAir Communications Manual page 9

CAT-5 Ethernet cable color codes
1 – White w/orange stripe
2 – Orange w/white stripe
3 – White w/green stripe
4 – Blue w/white stripe
Component
Cable
Crimp Tool
RJ-45 For Shielded 4-pair solid wire cable
Connectors
RJ-45 For Un-shielded 4-pair solid wire cable
Ethernet Cable Tester – Continuity only
Cable Tester
Complete Cable I/O Qualification Tester
Switches 7 RJ-45 Port and 1 ST Fiber Optic Port
* STP = Shielded Twisted Pair
** UTP = Unshielded Twisted Pair
QUANTUM™ LX AcuAir™ CONTROL PANEL
COMMUNICATIONS SETUP
5 – White w/blue stripe
6 – Green w/white stripe
7 – White w/brown stripe
8 – Brown w/white stripe
ETHERNET COMPONENT RECOMMENDATIONS
Description
Shielded solid 4-pair* (1000 Ft)
Shielded solid 4-pair*
Un-shielded solid 4-pair**
Un-shielded solid 4-pair** (1000 Ft)
RJ-45 Crimp tool
5 RJ-45 port
8 RJ-45 port
Because of the large number of possible configurations
in an Ethernet network, you most likely will not have any
type of automated installation software. This means that
you will need to manually configure all the options. To
configure these options for the Quantum™ LX, please re-
fer to the next section in this manual entitled Ethernet
Setup.
Part Number
BOXCAT5E-DSSO
E-PLG-SOLID-SH
CR45-100S
9504 CS
9504 F
E-PLG-SOLID
345U5-1000BLK
0-5EPCS-BK
HT-210C
P-15027
S2307692
10-RJ1145
P-15007
5-554169-3
1-5E45-010
P-15029
TST-5150
TS075A-R2
N/A
SFN-5TX
SFN-7TX/FX ST
SFN-8TX
090.510-CS (DEC 2012)
Page 9
