Frick® AB
Address Address
7061 N100:61
7091 N70:91
7093 N70:93
7094 N70:94
7100 N101:00
7101 N101:01
7102 N101:02
7104 N101:04
7105 N101:05
7106 N101:06
7107 N101:07
7120 N101:20
7121 N101:21
7122 N101:22
7124 N101:24
7125 N101:25
7126 N101:26
7127 N101:27
7140 N101:40
7141 N101:41
7142 N101:42
7144 N101:44
7145 N101:45
7146 N101:46
7147 N101:47
7160 N101:60
7161 N101:61
7162 N101:62
7163 N101:63
7164 N101:64
7165 N101:65
7166 N101:66
7167 N101:67
7168 N101:68
7169 N101:69
7170 N101:70
7171 N101:71
7172 N101:72
7173 N101:73
QUANTUM™ LX AcuAir™ CONTROL PANEL
COMMUNICATIONS SETUP
SETPOINT VALUES: (Read/Write)
Modbus
Address
47062 PSIG Offset
47092 Power Failure Restart Delay
47094 Panel Heater On Value
47095 Panel Heater Off Value
47101 Process 1 Cooling Setpoint
47102 Process 1 Cooling On
47103 Process 1 Cooling Lockout
47105 Process 1 Cooling Proportional Band
47106 Process 1 Cooling Integration Time
47107 Process 1 Cooling Command Maximum
47108 Process 1 Cooling Command Minimum
47121 Process 2 Cooling Setpoint
47122 Process 2 Cooling On
47123 Process 2 Cooling Lockout
47125 Process 2 Cooling Proportional Band
47126 Process 2 Cooling Integration Time
47127 Process 2 Cooling Command Maximum
47128 Process 2 Cooling Command Minimum
47141 Cleanup Cooling Setpoint
47142 Cleanup Cooling On
471443 Cleanup Cooling Lockout
47145 Cleanup Cooling Proportional Band
47146 Cleanup Cooling Integration Time
47147 Cleanup Cooling Command Maximum
47148 Cleanup Cooling Command Minimum
47161 Cooling Stage 1 On
47162 Cooling Stage 1 Minimum On Time
47163 Cooling Stage 1 Minimum Off Time
47164 Cooling Stage 2 On
47165 Cooling Stage 2 Minimum On Time
47166 Cooling Stage 2 Minimum Off Time
47167 Cooling Stage 3 On
47168 Cooling Stage 3 Minimum On Time
47169 Cooling Stage 3 Minimum Off Time
47170 Cooling Stage 4 On
47171 Cooling Stage 4 Minimum On Time
47172 Cooling Stage 4 Minimum Off Time
47173 Cooling Interstage Delay
47174 Cooling Outside Air Lockout Differential
090.510-CS (DEC 2012)
Description of Data
Page 71
