Johnson Controls FRICK QUANTUM LX AcuAir Communications Manual page 16

090.510-CS (DEC 2012)
Page 16
A sample of the original file appears in the following ex-
ample:
;Quantum to Quantum LX MAP Addresses
;Q,
0,
1,
2,
3,
4,
5,
6,
7,
Quantum™ earlier ad-
dresses
QUANTUM™ LX AcuAir™ CONTROL PANEL
COMMUNICATIONS SETUP
LX , LX Description
1026 ;Compressor Motor Start Signal
1027 ;Compressor Motor Starter-Feedback/Compressor Interlock
1028 ;Oil Pump Start Signal
1029 ;Oil Pump Feedback
1003 ;Capacity Increase
1002 ;Capacity Decrease
1005 ;Volume Increase
1004 ;Volume Decrease
Quantum™ LX
addresses
USB Memory Stick location
Q4
Quantum™ LX
Address Description
MapFile.txt Example
Q4/Q5
USB1
CN1000
Screen Resolution
COM3 COM4
RS-485 RS-485
USB2 LVDS1 COM2 COM1
Display RS-232 RS-232
Connection
Q5
CN PWR1 CN1
Power Ethernet
CN2
(Not Used)
JLVDS3
Backlight Control
JLVDS2
Backlight Level
INV 1
Inverter
CMOS1
CMOS Erase
TOUCH 1
Touch Panel
CN3
Touch Panel Type
USB6
CN4
USB5
Auto-Power
(See Note 2)
USB5
USB3
CRT
Video Monitor
