PCI-DAS6013 and PCI-DAS6014 User's Guide
Table 2. Absolute accuracy components specifications - All values are (±)
Range % of
Reading
±10 V 0.070
±5 V 0.020
±500 mV 0.070
±50 mV 0.070
1
Averaged measurements assume averaging of 100 single-channel readings.
Each PCI-DAS6013 and PCI-DAS6014 is tested at the factory to assure the board's overall error does not
exceed accuracy limits described in Table 1.
All ranges
No missing codes

System throughput

Condition
1. Single channel, single input range
2. Multiple channel, single input range
3. Single channel, multiple input ranges
For conditions 1-2 above, specified accuracy is maintained at rated throughput. Condition 3
Note 2:
applies a calibration coefficient which corresponds to the range value selected in
This coefficient remains unchanged throughout the scan. Increased settling times may occur
during gain-switching operations.

Settling time

Settling time is defined as the time required for a channel to settle to within a specified accuracy in response to
a full-scale (FS) step. Two channels are scanned at the specified rate. A –FS DC signal is presented to
channel 1; a +FS DC signal is presented to channel 0.
Condition
Same range to same range
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Offset Averaged Noise +
(µV) Quantization (µV)
1800 180
918 85
109 12
27 7
Table 3. Differential non-linearity specifications
±0.5 LSB ty,p ±1.0 LSB max
16 bits, guaranteed
Calibration Coefficients
Per specified range
Per specified range
Default to value for cbAInScan() range parameter
Range
±10 V
±5 V
±500 mV
±50 mV
32
Temp Drift (%/DegC)
1
0.001
0.001
0.001
0.001
Accuracy
±0.0031%
(±2.0 LSB)
5 µs typ
5 µs max
5 µs typ
*
Specifications
Absolute
Accuracy at FS
(mV)
8.984
2.003
0.471
0.069
ADC Rate (max)
200 kS/s
200 kS/s
200 kS/s
cbAInScan()
.
±0.0062%
(±4.0 LSB)
*
*
*
5 µs typ
