Recipes

Introduction to Recipes

A Recipe is a saved file that contains all the necessary test parameters for a particular container...

When to Load a Recipe

Note: Since guided setup accounts for the required leak test parameters it is not necessary to load a recipe after
performing a guided setup.

Loading a Recipe

From the home screen, select the settings
opens and allows for loading, creating, or deleting of recipes. Selecting any one option will navigate to further
action prompts.
Note: This Quick Start manual explains how to load an existing recipe. Please refer to the advanced operations
manual for further information on the recipe menu.
ALPS SC LINEAR QUICK-START GUIDE
If a recipe exists for a container it may already be
loaded into the SC leak tester instead of performing
the guided setup. Remember the current recipe
loaded is always viewable from the Home Screen.
After loading a recipe make sure the rails and
product detect PE are set correctly for the
production container.
button and then select
24
button. The Recipes menu
REV00 © 02/12/2014
RECIPES
