AIR LOGIC POWER SYSTEMS (ALPS)

HMI Emergency Stop and main Air Shut off

COMPONENT
1
SC Main Enclosure
2 SC HMI
Emergency Stop (E-Stop)
3
Red/Green Push Buttons
Main Air Regulator & Shut-
4
Off
5
Status Light
ALPS SC LINEAR QUICK-START GUIDE
Supports conveyor frame, provides guides/clamps for vertical
positioning of servo-slide mechanism.
Menu Display system (Human Machine Interface)
Immediately stops all activity. Removes power from Servo motor
and any PLC outputs. Starts and Stop leak test
Includes the Air Inlet, Regulator and Gauge. This component is set
to 60 PSI at the factory
Indicates production mode
iv
FUNCTION
REV00 © 02/12/2014
