Description - Siemens SIMATIC RUGGEDCOM RSG2100P Installation Manual

Introduction
1.2 Description
•
•
•
Universal Power Supply Options
•
•
•
•
•
1.2

Description

The RUGGEDCOM RSG2100P features various ports, controls and indicator LEDs on
the display panel for connecting, configuring and troubleshooting the device. The
display panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
1
2
3
4
5
6
7
Figure 1.1
Communication Ports
Port Status Indicator LEDs
2
-40 to 85 °C (-40 to 185 °F) operating temperature (no fans)
Conformal coated printed circuit boards (optional)
18 AWG galvanized steel enclosure
Fully integrated power supplies
Device power supply: 24 VDC (10-36 VDC), 48 VDC (36-59 VDC), 88-300 VDC or
85-264 VAC
Screw or pluggable terminal blocks for reliable, maintenance-free connections
CSA/UL 60950-1 safety approved to 85 °C (185 °F)
PoE power supply: 48 VDC
Fiber or Copper Ethernet Ports
Port Status Indicator LEDs
Mode Button
RS-232 Serial Console Port (RJ45)
Display Mode Indicator LEDs
Alarm Indicator LED
Power Module Indicator LEDs
RUGGEDCOM RSG2100P
1
Ports for communicating with other devices or accessing the
RUGGEDCOM RUGGEDCOM RSG2100P operating system are de-
scribed in "Communication Ports (Page
Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
Mode
Status Green (Solid)
Green (Blinking)
5
2 3
23)".
Color/State Description
Link detected
Link activity
RUGGEDCOM RSG2100P
Installation Manual, 01/2020, C79000-G8976-1041-16
6
7
4
