Display Mode Indicator LEDs
Mode Button
Alarm Indicator LED
Power Module Indicator LEDs
RS-232 Console Port
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RSG2100P:
AC power cord (16 AWG)
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #8-32 screws
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG2100P
Installation Manual, 01/2020, C79000-G8976-1041-16
Duplex
Speed
The display mode indicator LEDs indicate the current display mode
for the port status indicator LEDs (i.e. Status, Duplex or Speed).
The Mode button sets the display mode for the port status indicator
LEDs (i.e. Status, Duplex or Speed). It can also be used to reset the
device if held for 5 seconds.
The alarm indicator LED illuminates when an alarm condition exists.
The power module indicator LEDs indicate the status of the power
modules.
• Green – The power supply is supplying power
• Red – Power supply failure
• Off – No power supply is installed
The serial console port is for interfacing directly with the device and
accessing initial management functions. For information about con-
necting to the device via the serial console port, refer to
ing to the Device (Page
Tools/Materials
1.3 Required Tools and Materials
Mode Color/State
Off
Green
Orange
Off
Green (Solid)
Green (Blinking)
Orange (Solid)
Off
21)".
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
Introduction
Description
No link detected
Full duplex mode
Half duplex mode
No link detected
100 Mbps
1000 Mbps
10 Mbps
No link detected
"Connect-
Purpose
