Rugged Electrical Specifications; Oem Electrical Specifications - Advanced Navigation Motus Reference Manual

9.8

Rugged Electrical Specifications

Parameter
Input Supply Voltage
Input Protection Range
Tx Voltage Low
Tx Voltage High
Tx Short Circuit Current
Rx Threshold Low
Rx Threshold High
Output Voltage Low
Output Voltage High
Output Current
Input Voltage
Input Threshold Low
Input Threshold High
Table 14: Rugged electrical specifications
9.9

OEM Electrical Specifications

Parameter
Input Supply Voltage
Input Protection Range
Output Voltage Low
Output Voltage High
Output Current
Input Voltage
Input Threshold Low
Input Threshold High
Table 15: OEM electrical specifications
Power Supply
RS232
GPIO
Power Supply
Serial and GPIO Signal Levels
Motus Reference Manual
Page 28 of 146
Version 1.1
29/11/2019
Minimum Typical
5 V
-60 V
-5.7 V
5 V 6.2 V
0.8 V 1.3 V
1.7 V
0 V
4.8 V
-20 V
3.5 V
Minimum Typical
4.5 V
None
0 V
2.4 V
0 V
2 V
Maximum
36 V
60 V
-5 V
±70 mA
2.5 V
0.3 V
5 V
5 mA
20 V
1.5 V
Maximum
5.5 V
None
0.4 V
3.3 V
10 mA
5.5 V
0.8 V
