9.4

Rugged Communication Specifications

Parameter
Interface
Primary and Auxiliary Port Speed
GPIO Port Speed
Protocol
Peripheral Interface
GPIO Level
Table 10: Rugged communication specifications
9.5

OEM Communication Specifications

Parameter
Interface
Speed
Protocol
Peripheral Interface
GPIO Level
Table 11: OEM communication specifications
9.6

Rugged Hardware Specifications

Parameter
Operating Voltage
Input Protection
Power Consumption
Hot Start Battery Capacity
Hot Start Battery Charge Time
Hot Start Battery Endurance
Operating Temperature
Environmental Sealing
Shock Limit
Vibration Limit
Motus Reference Manual
Page 26 of 146
Version 1.1
29/11/2019
RS232 (RS422 optional)
2400 to 2 M baud
2400 to 250 K baud
AN Packet Protocol
2x GPIO and 1x Auxiliary RS232
5 V or RS232
3.3V TTL serial port (5V tolerant input)
2400 to 10M baud
AN Packet Protocol
2x GPIO and 1x Auxiliary serial port (3.3V
3.3V TTL (5V tolerant input)
5 to 36 V
0.95 W (typical)
> 48 hrs
30 mins
> 10 years
-40 °C to 85 °C
MIL-STD-810G
Value
NMEA
TSS1
Simrad
Value
TTL)
Value
-60 V
IP67
2000 g
8 g
