Description of the GXTRA/3

6.1 Main Features

Single-wide SBus card (83.82mm x 146.7mm) (3.3" x 5.8")
SBus-size two piece front panel
Single-slot card
PROM conforms to the Open Boot PROM 2.0 Specification
Slave-only SBus interface with SPARC CPU
4 Mb Address Space Required
Drives standard RGB monitors
8-bits per pixel (color & grayscale), plus 8-bits per pixel
overlay
256 colors from palette of over 16 million colors
256 overlay colors from palette of over 16 million colors
Accelerated 2-D vectors
Accelerated windowing functions, text, and fast raster
operations
Fast 2-D polygon fill
Design optimized for X Windows performance
Full Pixrect/Pixwin compatibility
Single connector to video monitor with embedded coax
Automatically initialized by the SPARC upon CPU power-up
Uses single-chip ASIC video sub-system
8-pin Mini-Din keyboard/mouse connector
3 color hardware cursor

6.2 Card Specifications

The following specifications are applicable to all GXTRA/3 Turbo
products. Reference section 4.5 for resolution dependent
specifications.
