Tech Source Raptor 4000-R Specification Sheet

T
o see the big picture, ATC and defense
require efficient display of airspace.
The Raptor 4000‑R and 4000e‑R hardware
video rotation offers new display options
for greater efficiency through highly
configurable resolution support
including 1600 × 2560 portrait
mode.
• 256 MB frame buffer
• Hardware video rotation
• Multi-mode resolution support and
layering via 8+8, 8 bit, 24 bit, 8+24 &
MOX modes
• DVI-I × 1 (digital/analog)
• PCI and PCI Express (short card) versions
• Comprehensive customer care including
long‑term technical support
• Support for Linux, Solaris & Tru64
F E A T U R E S
Hardware Video Rotation
The Raptor 4000-R and 4000e-R are the indus-
try's only boards to offer portrait mode display for
monitors of up to 30" without sacrificing advanced
2K × 2K
Primary Monitor
H i g h R e s o l u t i o n C o l o r V i d e o G r a p h i c s A d a p t e r s
30" Primary or Auxiliary
Monitor with Portrait Rotation
feature sets. These include 32 independent MOX
(Multiple Overlay eXtension) overlays and 8+8 video
mode supported on legacy ATC systems including
Tru64 UNIX and Solaris. They also offer these
same features to customers porting their applica-
tions to installations using Linux.
Maximum Performance and Flexibility
With 256 MB of on-board memory and an efficient
memory manager, the boards offer excellent draw-
ing performance and optimal pixmap management
with minimum host CPU usage. These products
offer maximum flexibility, supporting more video
modes than any other graphics boards currently
on the mar ket. In addition, traditional video
modes such as 8 bit, 24 bit and 8+24 are avail able
and selection is easily achieved through software
configuration.
