5.3 Frame Buffer Organization

The GXTRA/2 Turbo frame buffer is organized as a single 2
megabyte memory array.

5.4 Electrical Specifications

The following table provides the electrical parameters for the
GXTRA/2 Turbo card.

Table 5-1 GXTRA/2 Turbo Electrical Specifications

CONSIDERATION
Conditions
Supply Current
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
96-pin Mini-Din
83.82mm x 146.7mm (3.3" x 5.8")
Weitek Power 9100
IBM RGB525
2 MB
On board flash
Zilog 85C30 SCC
SPECIFICATION
5% tolerance on all power supplies
0
0
T/A = 10
to +50
C
Voltage = 5V
Board 1.1A nom 1.75A max
kbd/mouse 0.15A nom .25A max
total 1.25A nom 2.0A max
5-2
