Figure 2.4 Rear Panel Cover and Board Socket Locations for
SPARCstation 1+ and 2
2. With a ground strap (ESD kit) attached, open the anti-static
bag and remove the GXTRA. Place the card at an angle
into the rear panel of the workstation. Ensure that the
DB13W3 video connector is facing the rear of the unit and
the component side is facing up. Ensure that the card
mounting plate hooks into the slot opening on the rear
panel.
3. Align the connectors on the bottom of the card with the
connector on the main board (reference Figure 2.5).
Gently press the connectors into the socket. Press on the
corners of the board. Do not press on the plastic retainer
bracket.
