GXTRA Hardware Installation -September 11, 1997
Table 4-10 Switch A - 1600 x 1280 @ 60 Hz Timing Parameters
PARAMETER
Horizontal Resolution
Vertical Resolution
Vertical Frequency
Horizontal Front Porch
Horizontal Sync Width
Horizontal Back Porch
Horizontal Frequency
Vertical Front Porch
Vertical Sync Width
Vertical Back Porch
Table 4-11 Switch B - 1600 x 1280 @ 76 Hz Timing Parameters
PARAMETER
Horizontal Resolution
Vertical Resolution
Vertical Frequency
Horizontal Front Porch
Horizontal Sync Width
Horizontal Back Porch
Horizontal Frequency
Vertical Front Porch
Vertical Sync Width
Vertical Back Porch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
VALUE
1600
1280
60
0.19
1.60
1.41
79.3
0.0
25.2
529.7
VALUE
1600
1280
76
0.11
1.00
1.30
101.9
19.6
78.5
490.7
4-8
UNIT
Pixel
Pixel
Hz
usec
usec
usec
Khz
usec
usec
usec
UNIT
Pixel
Pixel
Hz
usec
usec
usec
Khz
usec
usec
usec
