GXTRA Hardware Installation - September 11, 1997
Attach a wrist grounding strap (or the supplied ESD device)
at this time. Do not proceed without properly grounding
yourself to the workstation.

2.5 Installing the GXTRA

Reference the documentation provided with your workstation for
specific details on card installation. For installing SBus cards in a
SPARCstation 10 and SPARCstation LX, reference the Desktop
SPARC Hardware Owner's Guide Appendix H and I. General
information for a SPARCstation 1+, 2, IPX, IPC, and SPARCclassic
follows.
2.5.1 SPARCstation 1+ and 2
The SPARCstation 1+ and 2 have three (3) SBus slots. You may
install the GXTRA in any slot. Reference Figure 2.3 for the SBus
slot locations.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
CAUTION
2-6
