8 en | System overview
3

System overview

The MAP control center consists of a housing with three LEDs and an LCD screen.
3.1

Housing with LEDs

Three light-emitting diodes (LEDs) are located on the left edge of the MAP control center
housing:
Element
1
2
3
3.2

LCD screen

How to operate the LCD screen
–
–
3.3

Main menu

Notice!
The buttons on your touch screen are determined by the user authorization level that has
been configured by the installer. Therefore, your touch screen might be different from what is
described in this manual.
2019-11 | 08 | F.01U.168.328
Component
Green LED
Yellow LED
Red LED
To operate the LCD screen, tap the icons and buttons shown on the screen with
moderate pressure.
To avoid damage of the LCD screen, do not use sharp objects during operation.
Description
Indicates that the control center is in normal condition.
Indicates that there is a trouble condition, that devices are
covered, or that devices of the system are bypassed or
disabled.
The default behavior indicates that an alarm condition exists
in the security system.
User manual
MAP Control Center
Bosch Security Systems B.V.
