MAP Control Center
Main menu - screen 1
Element
1
2
3
4
5
6
Bosch Security Systems B.V.
Component Description
Screen name This information identifies the active screen.
Menu buttons These buttons are used to perform tasks.
Installer mode icon This icon indicates that the control panel is in installer
mode.
RPS connected icon This icon indicates that remote programming software is
connected to the control panel.
Information button This buttons is used to view additional system information
and to clear events, alarms or troubles.
Flashing red: not yet cleared system events and alarms
Flashing yellow: not yet cleared system troubles
Green: no additional system information available
Navigation bar These buttons are used to navigate through the system, to
find tasks or to view system information. Grayed out
buttons are not activated.
User manual
System overview | en 9
2019-11 | 08 | F.01U.168.328
