Short information

This manual describes how to operate the MAP control center.
2.1

Introduction

The MAP control center is an input device for the MAP 5000 system.
Each control center has a vibrant-color 14 cm (5.7 inch) LCD screen. The durable touch screen
provides access to system functions through an interface with intuitive buttons. Users touch
the images directly on the screen to arm, disarm, or select other menu options. The display
text is shown in the language defined by the user.
2.2

Ambient conditions

Environmental
Minimum operating temperature in °C
Maximum operating temperature in °C
Minimum storage temperature in °C
Maximum storage temperature in °C
Minimum relative humidity in %
Maximum relative humidity in %
Protection class
Security level
Environmental class
Usage
2.3

Certifications

The system is designed to comply with the certifications and approvals listed here.
Region
Germany
Europe
Europe
Switzerland
France
2019-11 | 08 | F.01U.168.328
Agency Certification
VdS Class C, VdS G 111040
CE Conformité Européene
EN EN 50131-1:2006 + A1:2009
EN 50131-3:2009
EN 50131-6:2008
EN 50136-2/SP4/DP3
EN 50131-10
SES Association of Swiss Installers of Security Systems
Edition V3 / 01.01.2011-d
AFNOR / CNPP NF&A2P Grade 3
Cert. Certificate Number ICP-MAP5000-2: 1133400003
Certificate Number ICP-MAP5000-COM: 1230200016
