RFID area:
RFID card comes together with HC8200. It is a safety design, allows machine to identify the parameter and types of
consumable.
Please note that granules RFID card can increase the single machine specific working time. The card is disposable, can
only use once.
Interface

Main interface:

593 582
DMX 1
First Line: Shows inner core temp. of Nozzle 1, inner core temp. of Nozzle 2, Spinning speed respectively.
Second Line: DMX address, error info. If available, remain working time.

Error information:

Error Informations
E0 System IC
E2 Temp. Sensor
E3 P Temp. Over
E4 Time Remain
E5 K Temp. Over
E6 Heat Fail
3
RPM 70
60.00
Explanation
Systematic error
Temperature sensor is not connected or damage
Chassis over-temperature
Activated time for machine is not enough, need to swip RFID card
Inner core over-temperature
Heating fail, if it self recovery, please pay attention to the power supply.
