Technical Specifications; Operation Panel - Showven SPARKULAR SPIN User Manual

Technical Specifications

Product name
Model
Dimension
Weight
Input
Work Power
Hopper capacity
HC8200 consumption rate
Work Temp.
Effect Height
Casing Material
Interface
Control

Operation Panel

LED display area:
READY DMX
READY: Flashing means heating up, about 5min. Turns from flashing into long on, indicates that the machine is ready
to work.
DMX: Flashing shows that DMX signal is connected, light OFF means there is no DMX signal
FAULT: Light ON when error occurs
HEAT: Light ON when system is heating up
Control Button Area:
MENU: switch through setup menu. Press 3s switch to advanced interface
DOWN: parameter down
UP: parameter up
ENTER: confirm and save parameters
SPARKULAR SPIN
BT81/BT82
330x305x349mm
20Kg
AC220V,50/60Hz
AC110V,50/60Hz
1000W
200g*2
20g/Min*2
-20°C~40°C
HC8200 LARGE: 2-5m adjustable
HC8200 MEDIUM: 2-4m adjustable
304 stainless steel
NEUTRIK POWER IN/OUT, both 3-pin and 5-pin XLR
Wireless remote
DMX: 2 channel/ 4 channel for professional use
FAULT HEAT
2
