Front Panel - ADTEK CS1-SG Operation Manual

Hi.HLd (Lo.HLd): When the PV Higher (or lower) than
set-point, the relay will be energized and latch until
manual reset by from key in【User Level】.
Hi or Lo Relay Energized
Hi Setting
Lo Setting
Hi Relay Energized
ON
Lo Relay Energized ON
FIELD CALIBRATION(This function is for CS1-SG, CS1-PM & CS1-RS)
In pass time, engineers have take a lot of time to adjust meters or converter to meet the structure of machinery zero
and span for the Load Cell and Potentiometer measuring. Now, our CS2-SG & CS2-PM support easlier process to
do it called "Field Calibration".
Adjust the structure of machinery to be "zero status".
Enter the right pass code of the meter to get into the Field Calibration Level.
Move page to the CAL.Lo , and press
device. After it done, the page will change to CAL.Hi automatically. The low point will be the new zero.
Adjust the structure of machinery to be "span status".
In CAL.Hi page, press
the page will change to C.SEL automatically. The high point will be the new span.
Reading the signal will take few seconds.
Please check the setting of high scale Hi.SC and low scale Lo.SC again, after the "Field Calibration" has done.
C.SEL(Calibration parameter selection): Field calibration don't change the default calibration. So, after you do field
calibration, you can select default calibration if you want.
■ APPLICATIONS
Switch Boards
Motor Control Boards
Display Voltage or Amp for Mechanical Equipment
Machinery Control
Process Control Systems for pressure, level,....
sensing transducers
Automation System
Testing Instruments
AO
AL
RS 485
COM
R L 1
~A
ENT/FN ◄ ▲ ▼
Measuring Input

■ FRONT PANEL

Relay status
Indication
R L 1
Operation Key
ENT/FN ? ?
Hi(Lo) Energized Hold & Reset
Hi Setting
Hi.HLd(High Hold)
Relay Energized ON
Reset the relay Hold
Level Trigger
by ECI or Front Key
Key to stand by. Press
ENT
Key to stand by. Press
ENT
Coil of Transformer
Coil of Motor
Comm. status
CO M
Display screen
?
■ ANALOGUE OUTPUT FUNCTIONS
SCALE Default: Ai.Lo: 0%, Ai.Hi: 100%; Lo.SC: 0.00, Hi.SC: 100.00
Change to Ai.Lo: 0%, Ai.Hi: 75%; Lo.SC: 0.00, Hi.SC: 199.99
199.99
100.00
0.00
INPUT
ON 0.00% 50.00%
Key again to read the signal low of sensing
ENT
Key again to read the signal high of sensing device. After it done,
ENT
RS 485 Modbus RTU Mode (up to 38400bps)
Analog Output 0~10V/0(4)~20mA
AL AL
COM
RL 1 R L 1
~A
◄ ▲ ▼ ◄ ▲ ▼
ENT/FN EN
■ INSTALLATION
R
ENT/FN ? ? ?
PANEL CUT-OUT:
92 (W) x 44 (H) mm
+0.2 +0.2
2 / 10 CS1-SERIES (V1.0) OPERATION MANUAL 2006-10-26
Setted Scaling: Lo.SC: 0.00, Hi.SC: 199.99;
SCALE
Desired Output: Ao.Lo: 50.00(PV), Ao.Hi: 150.00(PV)
199.99
150.00
100.00
50.00
0.00
OUTPUT
75.00% 100.00% 0.00%
1 Relay Output:
Mode: High or Low Energized
Functions: Start delay / Energized &
De-energized delay / Hysteresis
COM
Display:
Hz Mode: Measuring Value / Maximum Hold /
Minimum Hold / Reading value from
RS485 command
Field Calibration(CS1=SG and CS1=PM only):
The meters can be calibrated for zero and span
with STRAIN GAUGE (POTENTIOMETER)
transducers in field.
C O M
FIX HOLDER:
72 mm(L) / W M3
1.0~8.0 mm
50.00% 100.00%
