User Level - ADTEK CS1-SG Operation Manual

: Display is negative-overflow (Singal is under display range)
: ADC is positive-overflow (Signal is higher than input 120%)
: ADC is negative-overflow (Signal is lower than input -120%)
/
/
/
/
/
*Please enter to Engineer Level to check and set the parameters when users start to install the meter
*KEY FUNCTIONS:
SHIFT: (1) In each Function Index Page, press this key about 1 second will return to the
Function Group.
(2) In Function Setting Page, press this key about 1 second will return to the
Function Index page.
(3) During Setting, press this key will move the bright digit (i.e. can be adjusted digit)
UP: (1) During number Setting, press this key can roll the digit up.
(2) In Function Setting Page, press this key can switch functions.
(3) In Function Index Page, press this key will back to the last Function Index Page.
DOWN: (1) During number Setting, press this key can roll the digit down.
(2) In Function Setting Page, press this key can switch functions.
(3) In Function Index Page, press this key will go to the next Function Index Page.
ENTER: Press this key to confirm and save the setting.
ENT
OPERATING DIAGRAM:
■

USER LEVEL

Power on
Self-diagnosis
Display the model
number
CS1.vA: (Volt/Current)
CS1.Pr: (10V/20mA)
CS1.SG: (Strain Gauge)
CS1.PM: (Potentiometer)
Display the software
version
MEASURING PAGE
Press 1sec.
Press
ENT
Enter the password to
get into Engineer Level
ENT
Correct
NO
YES
Default=1000
ENGINEER LEVEL
INPUT GROUP
: EEPROM occars error
: Calibrating Input Signal do not process
: Calibrating Input Signal error
: Calibrating Output Signal do not process
: Calibrating Output Signal error
USER LEVEL
Press for 1 second can back to Measuring Page
0
Pv: Present Value
− If the display function has
been setted RS485, the
0
▼ ▲
Measuring Page will show the
−
number what is from RS485
1
command. The reading will
move to this step for checking
0
rY.1.SP.: Relay 1 Set-point
− setting
(default:10000)
1
▼ ▲ Settable Range: 0~29999
0
rY.rSt: Reset for energize
− hold of Relay
Selectable: YES / no
2
▼ ▲
0
Min:PV Minimum storage
−
3
1sec.
▼ ▲
Press to enter & setting
ENT
Press to enter & select
ENT
5 / 10 CS1-SERIES (V1.0) OPERATION MANUAL 2006-10-26
(Please check the input
signal)
(Please check the input
signal)
(Please check the input
signal)
(Please send back to
manufactory for repaire)
(Please process Calibrating
Input Signal)
(Please check Calibrating
Input Signal)
(Please process Calibrating
Output Signal)
(Please check Calibrating
Output Signal)
In Engineer Level, the
screen will return to
Measuring Page after do
not press any key over 2
minutes, or press
for 1 second.
0
MAX:PV Maximum storage
−
4
▼ ▲
0
M.rSt: Maximum & Minimum
− storage reset
Selectable: YES / no
5
▼ ▲
Press
ENT
0 CS1.Pr: The model number
vEr1.0: fameware version 1.0
−
6
▼ ▲
0
Cyclic to first page
−
1
▼ ▲
to enter & select
