5. FOOTBOARD COMPONENTS

The components at the front right of the footboard are identified as follows:
14. Forward movement pedal
15. Backward movement pedal
16. Brake pedal
17. Parking brake pedal
18. Battery charger plug insertion hatch

6. SEAT SUPPORT COMPONENTS

The seat support components are identified as follows:
19. Seat lifting handle
20. Safety belt (optional)
21. Solution tank drain pipe
22. Recovery tank drainage tube
23. Recovery tank discharge cap
PREPARATION OF MACHINE
13
16
15
14
17
18
19
23 22
10
21
