3. Specifications

Product
Horizontal/Vertical Beam Accuracy
Plumb Down/ Up Point Accuracy
Self Leveling Range
Water & dust-proof
Recommended Working Range
Laser Source
Classification
Tripod mount
Rotational Speed (rpm)
Rotational Coverage (scanning function)
ROTARY 400 HV Servo
± 0.15 mm/m
±0,175 mm/m
±5°
Indoor/outdoor IP 54 (International Electrotechnical Commission)
400 m diameter with Laser Detector
635 nm laser diode
Class II
5/8"
0 (stationary point), 120, 300, 600 rpm
0° (stationary point), 10°,45°, 90°,180°
