MAG-EXT Height Adjustment
Step 1
To adjust the height of the MAG-EXT Mount, hold the
weight of the projector and loosen the two (2)
M6 x 12mm security screws.
®
Slide the adjustable suspension neck into the desired
position.
¯
Retighten the two (2) M6 x 12mm security screws.
Do not release the projector until the M6 screws are
completely tight.
Technical Specifications
All measurements are in inches [millimeters].
Page 12
Visit the Premier Mounts website at http://www.mounts.com
MAG-EXT
M6 x 12mm
Security Screw
Installation Instructions
