Vfd Description; Menu Description - ITech IT6302 User Manual

I-set I-set
/Menu
Recall
/Save
Enter
/Lock
On/Off
(Shift)+1, (Shift)+2,
(Shift)+3

3.3 VFD Description

Explanation of enunciators on the display
CC In constant current mode
CV In constant voltage mode
open the remote sense
function
Indicates the shift button is
pressed
Indicates the channel
currently selected
SEr Open serial connection mode
PArA Open parallel connection
mode
TRA Enable tracking mode

3.4 Menu Description

Press (Shift)+
use the right/left key to change the setup, and up/down key to scroll through the complete
menu items. Press
Use to set the current or shift+I-set to enter the menu
operation.
Save or recall different operating parameters in memory
locations
Switch the display between setting value and actual value
Enter button to confirm the selection or setup/Shift+Enter to
lock the front keys
Use to control the output state of each channel
Right/Left key, use to move the cursor or scroll through the
menu items
Up/down key, use to increase or decrease the setting value
Use to turn on the output of corresponding channel no matter
in menu operation or Meter state
(Menu) to indicate operation mode.View the menu on the VFD,and
Enter
to enter the selected menu function.Press
17
IT6302 user manual
Esc
button to return
