display as follows:
TRAC
OFF ON
Picture 16
Select "ON" by left-right key and press
mode and the VFD will display "TRAC SUCC". After two seconds later, the system will
automatically exit the Menu.
When output is off and in Meter status, VFD will display:
Picture 17
In setting status, if voltage of CH1 is set as 2V, voltage of CH2 will be automatically sync to
4V (in scale)
If don't need sync function, please set the TRAC to OFF status. The steps as follow: press
(Shift) +
left-right key and at last press
seconds later, the system will automatically exit the Menu.
Notice: if the voltage/current of CH1/CH2 is set as zero before sync, voltage/current
synchronous operation of this channel will be ignored.
If need to check whether it is in sync status, please change output to OFF and
check in Meter status. There is no TRAC mark in normal status.
Power Information
Press (Shift) +
following parts:
Power Model
Display the model of power supply: IT6302
Soft Version
Software version of power supply: 1.XX
Press left-right key or conversion knob, will display the following information:
Series number of product
(Menu)into Menu, and press
, VFD will display power information; the information includes the
to set CH1 and CH2 in synchronous
to select TRAC, and select OFF by
to confirm, VFD display "OFF SUCC", after two
25
