6.5.2 „Quick Setup" menue
In Quick Setup, basic configuration options are combined to make it possible to quickly
configure key functions. All functions of the quick setup can also be found at another posi-
tion in the menue tree.
The following functions are available in the Quick Setup menue:
Menue entry
Sprache/Language
Level wizard
Damping
Device ID
Config.-memory
6.5.3 "Level" menue
All settings to parameterise the level measurement can be found in the "Level" menue.
Menue item
Level wizard
Density
Height offset
Tank shape
Status
BA_078 Rev 1F6 Level transmitter PASCAL Ci4 LEVEL
Description
Select menue language
Guided parameterisation of the fill level measurement (see
6.5.3.1)
Setting the damping of the output signal (see 6.5.6.1)
Setting the device ID (see 6.5.10.1)
Configuration memory: reading, writing and status (see 6.5.10.3)
Table 7: "Quick Setup" menue
Description
Guided parameterisation of the fill level measurement
View/change or teach-in the density and select a unit
View/change or teach-in the height offset and select a unit
Enter, teach-in and manage the tank shape for volume and
weight measurement
Display the status of the level measurement
Table 8: "Fill level" menue
