Operation
Note that if you open the lexan door (13) – Fig. L – the machine, for security reasons, stops; so pay attention
to close it perfectly so that you give the security switch. During the production be sure to have always pasta
sheet on the rollers, because if the stuffing goes on coming out, it could dirty the mould. When the piston (7)
of stuffing reaches the bottom of the cylinder (8) – Fig. D – the machine automatically stops; you must set the
cylinder free and fill it again with stuffing. At the end of the production, you must finish the remaining pasta
sheet starting the machine with the lever (5) in the position of unhooking – Fig. H.
CHANGING THE MOULD
Remove the carter (10) – Fig. I – and extract the mould (14) – Fig. M – pulling it towards you by the handle.
WARNING: Handle the mould with care, because eventual pushes may damage it, affecting production.
Each mould must be coupled with the proper distributor. To insert a new mould, you must push it letting it to run
in the proper guides, till the coupling of the gears. If you find it difficult, you can start the machine pressing the
MAN push-button and going on pushing the mould till the coupling of gears. Place the distributor of the mould
and close the carter (10) – Fig. I.

Maintenance

CLEANING
After use, clean perfectly the distributor (9) – Fig. E – and the container (8) – Fig. D – after dismounting them.
Also clean the piston (7) – Fig. D – with a damp cloth.
WARNING: While the machine is working, do not make any operation of cleaning and above all do not
draw object of any kind to the thinning cylinders (clothes, knives, spatulas, etc.).
If you need to clean the mould, do so only after extracting it from the machine and with a small brush and a
little damp cloth.
REFERENCE
Item Number Model Number
46296 PM-IT-0030-R
Description
Ravioli Machine 55 lbs. / 25 kgs.
8
Manufacturer Model Number
RV 30
