- Page 1 Refrigerated Sandwich Prep Units Models PT-CN-0686, 1194, 1524, 1778, 0711-M, 1194-M, 1537-M Items 24265, 24266, 24274, 24267, 27953, 24268, 24275 Instruction Manual Revised - 11/02/2016 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model PT-CN-0686 / Model PT-CN-1219 / Model PT-CN-1524 Model PT-CN-1778 / Model PT-CN-0711 / Model PT-CN-1194 / Model PT-CN-1537 Section Page General Information ----------------------------------------------------------------------------------------- 3 - 4 Safety and Warranty ---------------------------------------------------------------------------------------- 4 - 5 Technical Specifications ---------------------------------------------------------------------------------------- 6... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Do not attempt to alter or tamper with the electrical cord. 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
-
Page 6: Technical Specifications
Technical Specifications REFRIGERATED PREP TABLES Model PT-CN-0686 PT-CN-1194 PT-CN-1524 PT-CN-1778 Temperature Range 0°C ~ 10°C / 32°F ~ 50°F Horsepower 0.52 HP 0.82 HP 0.99 HP Electrical 110 V / 60 Hz / 1PH Amps Refrigerant R134a Isolation Material R141B... -
Page 7: Installation
Installation IMPORTANT!!!PLEASE READ BEFORE INSTALLATION • If the unit has recently been transported. Please let unit stand still for a minimum of 24 hours before plugging it in. • Make sure that the unit drops down to desired temperature before loading the unit with product. •... -
Page 8: Maintenance
Installation will eventually result in a warmer cabinet temperature. LOADING PRODUCT Shelves have been factory-installed for your convenience. Before loading shelves, please be sure that all shelf clips are completely fastened in their correct locations. It is important that all shelves rest completely level before stocking your cabinet with product. -
Page 9: Troubleshooting
Maintenance CLEANING THE INTERIOR OF UNIT • When cleaning the cabinet interior, use a solvent of warm water and mild soap. • Do not use steel wool, caustic soap, abrasive cleaners, or bleach that may damage the stainless steel surface. •... - Page 10 Troubleshooting Condensing unit runs for long • Excessive amount of warm • Allow adequate time for periods of time. product Placed in cabinet. Product to cool down. • Prolonged door opening or • Ensure doors are closed when door ajar. not in use.
-
Page 11: Controller Instructions
Controller Instructions Digital controller model: PJEZ for cooler Display and functions During normal operation, the controller displays the value of the probe set using parameter/4(=1 ambient probe, default, = 2 second probe, = 3 third probe).In addition, the display has LEDs that indicate the activation of the control functions (see Table 1),while the 3 buttons can be used to activate/deactivate some of the functions(see Table 2). - Page 12 Controller Instructions Table of Functions activated by the buttons - Models S, X, Y, C (Table 2) Button Normal Operation Start Up Pressing the Button Alone Pressed Together More than 3 sec: toggle ON/ Start/Stop ON/OFF continuous cycle Down More than 3 sec: start/stop Pressed For 1 sec.
- Page 13 To exit the menu without saving the changed values (exit by timeout) do not press any button for at least 60 s. REFERENCE Item Number Model Number Description Manufacturer Model Number Refrigerated Prep Table 27” / 686mm 24265 PT-CN-0686 SCL-1 110V/60/1 ETL cETLus Refrigerated Prep Table 47” / 1194mm 24266 PT-CN-1194 SCL-2 110V/60/1 ETL cETLus Refrigerated Prep Table 60”...
-
Page 14: Parts Breakdown
Parts Breakdown Model PT-CN-0686 24265... - Page 15 Parts Breakdown Model PT-CN-0686 24265 Item No. Description Position Item No. Description Position Item No. Description Position 26744 Cabinet for SCL-1 28179 Down Right Hinge for SCL-1 26778 Filter for SCL-1 26745 Door for SCL-1 26762 Up Right Hinge for SCL-1...
- Page 16 Parts Breakdown Model PT-CN-1194 24266...
- Page 17 Parts Breakdown Model PT-CN-1194 24266 Item No. Description Position Item No. Description Position Item No. Description Position 26192 26246 Castor for SCL-2 Temperature Controller Knob for SCL-2 26817 Condenser for SCL-2 26485 26794 Right K Strip for SCL-2 26806 Air Director for SCL-2 26818 Installing Panel for SCL-2 26795...
- Page 18 Parts Breakdown Model PT-CN-1524 24274...
- Page 19 Parts Breakdown Model PT-CN-1524 24274 Item No. Description Position Item No. Description Position Item No. Description Position 26246 Castor for SCL2-60 26902 Control Panel for SCL2-60 26913 Fan Install Panel for SCL2-60 26891 26892 Right K Strip for SCL2-60 26903 Power Switch for SCL2-60 26914 Outside Water Tray for SCL2-60...
- Page 20 Parts Breakdown Model PT-CN-1778 24267...
- Page 21 Parts Breakdown Model PT-CN-1778 24267 Item No. Description Position Item No. Description Position Item No. Description Position 26842 Cabinet for SCL-3 26859 Down Right Hinge for SCL-3 26876 Filter for SCL-3 26843 Door for SCL-3 26860 Up Right Hinge for SCL-3 26877 Compressor for SCL-3 26844...
- Page 22 Parts Breakdown Model PT-CN-0711-M 27953...
- Page 23 Parts Breakdown Model PT-CN-0711-M 27953 Item No. Description Position Item No. Description Position Item No. Description Position 28113 Cabinet for SCLM1 28133 Evaporator for SCLM1 28153 Condenser Fan Cover for SCLM1 Mounting Plate of Evaporator Fan for 28114 Door for SCLM1 28134 28154 Filter Bracket for SCLM1...
- Page 24 Parts Breakdown Model PT-CN-1194-M 24268...
- Page 25 Parts Breakdown Model PT-CN-1194-M 24268 Item No. Description Position Item No. Description Position Item No. Description Position 26246 Castor for SCLM-2 26951 Control Panel for SCLM-2 26962 Fan Install Panel for SCLM-2 26940 26941 Right K Strip for SCLM-2 26952 Power Switch for SCLM-2 26963 Outside Water Tray for SCLM-2...
- Page 26 Parts Breakdown Model PT-CN-1537-M 24275...
- Page 27 Parts Breakdown Model PT-CN-1537-M 24275 Item No. Description Position Item No. Description Position Item No. Description Position 26246 Castor for SCLM2-60 27000 Control Panel for SCLM2-60 27011 Fan Install Panel for SCLM2-60 26989 26990 Right K Strip for SCLM2-60 27001 Power Switch for SCLM2-60 27012 Outside Water Tray for SCLM2-60...
-
Page 28: Electrical Schematics
Electrical Schematics Model PT-CN-0686 24265... - Page 29 Electrical Schematics Model PT-CN-1194 24266...
- Page 30 Electrical Schematics Model PT-CN-1524 24274...
- Page 31 Electrical Schematics Model PT-CN-1778 24267...
- Page 32 Electrical Schematics Model PT-CN-0711-M 27953...
- Page 33 Electrical Schematics Model PT-CN-1194-M 24268...
- Page 34 Electrical Schematics Model PT-CN-1537-M 24275...
-
Page 35: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 36 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
