Omcan PM-IT-0030-R Instruction Manual page 17

Model PM-IT-0030-R
Item No. Description
AB852 Key 6x6x30 for RV 30
AB818 Electric Connection for RV 30
AB940 Washer for RV 30
AB941 Key 6x6x10 for RV 30
AB819 Key 5x5x10 for RV 30
AB904 6000 2R-S Bearing for RV 30
AB905 M8 Foot for RV 30
AB874 Filling Disengage Spring for RV 30
AB820 Gear Support for RV 30
AB821 Left Side for RV 30
AB822 Motor Shaft for RV 30
AB823 Chain Bush for RV 30
AB824 M2 Z20 Die Group Gear for RV 30
AB825 3/8" Z17 Sprocket Wheel for RV 30
AB826 3/8" Z17 Sprocket Wheel for RV 30
M2 Z26 Calibrating Rollers Gear for
AB827
RV 30
AB828 M2 Z23 Gear for RV 30
AB942 M2 Z29 Gear for RV 30
AB853 M2 Z15 Motor Gear for RV 30
AB906 Filling Cam for RV 30
AB907 Filling Dispenser for RV 30
AB875 Handle Washer for RV 30
AB876 Handle Washer for RV 30
AB877 Piston Shaft M2 Z12 for RV 30
AB878 Rack for RV 30
AB879 M2 Z39 Gear for RV 30
AB829 Main Side for RV 30
AB854 Filling Side for RV 30
AB855 Filling Regulation Block for RV 30
AB856 Filling Outlet Support for RV 30
AB908 External Support Plate for RV 30
AB857 First Calibrating Roller for RV 30
AB858 Driven Calibrating Roller for RV 30
AB859 Adjustable Calibrating Roller for RV 30
AB830 Spacer for RV 30
AB860 Rollers Pillow for RV 30
AB909 Swinging Lever for RV 30
AB910 Pushing Lever for RV 30
AB880 Short Bush for RV 30
AB861 Scraper for RV 30
AB911 Pushing Lever Bush for RV 30
AB881 Filling Disengage Bar for RV 30
46296
Position Item No. Description
31 AB882 Spring for RV 30
470 AB883 Handle Shaft Right Support for RV 30
984 AB884 Handle Shaft Left Support for RV 30
1017 AB912 Head Group Bar for RV 30
1428 AB885 Main Plate for RV 30
2081 AB886 Filling Disengage Plate for RV 30
4005 AB913 Filling Cylinder for RV 30
8066 AB914 External Support Plate Spacer for RV 30
18533 AB915 Filling Cam Spacer for RV 30
18535 AB916 Cam Washer for RV 30
18540 AB917 Brass Cam Spacer for RV 30
18541 AB918 Swinging Lever Spacer for RV 30
18542 AB919 Swinging Lever Washer for RV 30
18543 AB920 Rotation Support Washer for RV 30
18544 AB887 Spring Washer for RV 30
18546 AB862 Spacer for RV 30
18547 AB921 Filling Block Lever Left Spacer for RV 30
Filling Block Lever Right Spacer for
18549 AB922
RV 30
18551 AB888 Rack Bush for RV 30
18552 AB923 Rotation Support for RV 30
18555 AB924 Filling Block Lever for RV 30
18556 AB925 Pushing Block Lever for RV 30
18557 AB889 Filling Plate for RV 30
18558 AB890 Filling Plate Support for RV 30
18559 AB891 Filling Handle for RV 30
18566 AB863 Front Panel Shaft for RV 30
18570 AB892 Rotating Handle M6 for RV 30
18571 AB864 Knob M6x16 for RV 30
18572 AB926 Filling Gear for RV 30
18573 AB943 Right Side for RV 30
18574 AB944 Support Roller for RV 30
18575 AB945 Molder Roller for RV 30
18576 AB946 Spacer for RV 30
18577 AB947 Support Roller Scraper for RV 30
18578 AB893 Rack Brake Spring for RV 30
18579 AB948 Left Side for RV 30
18580 AB894 Support Pivot for RV 30
18581 AB895 Stuff Cylinder Pivot for RV 30
18583 AB865 Front Panel for RV 30
18586 AB831 Motor Shaft Spacer for RV 30
18587 AB832 Die Group Motor Shaft for RV 30
18588 AB866 Filling Regulation Screw for RV 30
Parts Breakdown
Position Item No.
18589 AB927
18590 AB896
18591 AB833
18592 AB834
18593 AB835
18594 AB836
18598 AB837
18600 AB838
18601 AB928
18602 AB949
18603 AB950
18604 AB867
18605 AB839
18606 AB840
18607 AB868
18608 AB841
18611 AB929
18612 AB842
18613 AB869
18614 AB930
18615 AB931
18616 AB897
18617 AB898
18618 AB843
18619 AB844
18620 AB845
18622 AB846
18624 AB870
18625 AB899
18626 AB932
18627 AB933
18628 AB951
18629 AB952
18631 AB871
18634 AB934
18635 AB847
18637 AB935
18638 AB936
18639 AB937
18641 AB872
18642 AB938
18692 AB873
17
Description Position
Sheet Roller Support for RV 30 18697
Rack Brake for RV 30 18699
Silicone Spring for RV 30 18721
Support Washer for RV 30 18728
Calibrating Rollers Bush for RV 30 18729
Bush 15x20x20 for RV 30 18730
Bush 18x23x15 for RV 30 18731
Bush 20x25x18 for RV 30 18732
External Support Plate Bush for RV 30 18733
Sliding Bush for RV 30 18734
Fixed Bush for RV 30 18735
Safety Switch Cam for RV 30 18745
Adjustable Bush for RV 30 18746
N.2 Spacer for RV 30 18749
M2 Z15 Gear for RV 30 18752
N.3 Spacer for RV 30 18801
Ravioli Chute for RV 30 18803
Metal Ring for RV 30 18808
Key 5x5x15 for RV 30 18861
Return Spring for RV 30 18862
Pushing Block Lever Spring for RV 30 18863
Disengage External Spring for RV 30 18864
Disengage Internal Spring for RV 30 18869
Switch Spring for RV 30 18872
Switch Spring Support for RV 30 18873
Switch Bush for RV 30 18874
Switch Washer for RV 30 18875
Scraper Bar for RV 30 18879
Long Bush for RV 30 18880
Filling Cam Bush for RV 30 18881
Die Group Fixing for RV 30 18882
Frontal Plate for RV 30 18897
Molder Roller Scraper for RV 30 18898
Filling Indication Screw for RV 30 18899
Back Panel for RV 30 18900
Disengage Lever for RV 30 18901
Frontal Panel for RV 30 18902
Lateral Panel for RV 30 18903
Top Panel for RV 30 18904
Filling Regulation Plate for RV 30 18911
Support Leg for RV 30 18912
Safety Switch for RV 30 20595
