Omcan PM-IT-0030-R Instruction Manual page 18

Parts Breakdown
Model PM-IT-0030-R
Item No. Description
AB939 M10 Knob for RV 30
AB848 M8 Stainless Steel Nut for RV 30
AB900 Stainless Steel M6 Washer for RV 30
46296
Position Item No. Description
30002 AB901 Stainless Steel M6 Nut for RV 30
VT204 AB902 Stainless Steel M6x25 Screw for RV 30
VT406 AB849 ZN M6x80 Screw for RV 30
Position Item No.
VT413 AB850
VT540 AB851
VT586 AB903
18
Description Position
M4x20 Stainless Steel Screw for RV 30 VT595
M8x25 Stainless Steel Screw for RV 30 VT651
6x30 Pin for RV 30 VT658
