Chapter1 Inspection and Installation
1.1 Inspection
Make sure that you have received the following compontents in the table below (one
instrucment for example).If anything has been lost, please contact with your franchiser.
Item
One power
cord
One user's
manual
One test
report
1.2 Cleaning
Do not clean any internal parts of the electronic loads casually.If you need to clean the
outside cover, please use a dry cloth or moistish cloth to wipe.
Caution: Cut the power off before cleaning.
1.3 Installation
The following outside drawing has marked the dimension information.The instrucment
should be fixed in a ventilation and reasonable size of space.
1.3.1 Mounting Dimensions
IT8511+/IT8512+/IT8512B+/IT8512C+ Dimension：
214.5 mmW x 88.2mm H x 354.6mm D
Refer to the following dimension drawing:
Part Number Description
IT-E171
You can choose different power cord
IT-E172
according to your region.
IT-E173
IT-E174
Installation,operation,self-test information
Calibration report
7
IT8500 USER MANUAL
User Manual
