(Gray-white)
9
0
～
ESC

2.6 Combination keys

Press (Shift) button first and then other keys to achieve all kinds functions in the
following table.
+1(Short)
+2(Tran)
+3(List)
+4(Save)
+5(Battery)
+6(Prog)
+7(Info)
+8(System)
+9(Config)
+0(Pause)
+ (Trigger)
+CC(OCP)
+CV(Setup)
+CW(OPP)
+Enter(Recall)
+On/Off(Lock)
User Manual
Power on button
Enter the digits 0 to 9.
Decimal point
The escape key
Choose constant current mode.
Choose constant voltage mode.
Choose constant resistance mode.
Choose constant power mode.
Enter the selected value or setting.
Turns DC Load ON or OFF (OFF is high impedance state).
Scroll up key
Scroll down key
Scroll left and right key
Turn short circuit on or off.
Start or stop transient condition.
Set LIST operation parameters.
Store the DC Load state in non-volatile memory.
Turn on or off battery testing function.
Enter auto tese function.
Display product's Model/SN/Version.
System menu setting
Configure menu setting
Press this button if you need a pause when runing an auto test
file.
Cause an immediate trigger.
Enter OCP test function.
Set detailed parameters in CC/CV/CW/CRmode.
Enter OPP test function.
Recall the DC Load state from non-volatile memory.
Key lock function
20
